Robustel GoRugged R3000 Quad User Guide
RT_UG_R3000 Quad_v.1.2.0 02.07.2015 43 / 136
Confidential
Client
DHCP server and user do not need to set the Primary and Secondary
DNS Server.
Override DHCP Server
Values @ DHCP Client
Router will use the follow preset Netmask and Gateway instead of the
addresses which obtained from the DHCP server.
192.168.0.2/
192.168.0.10
0
Username @ PPPoE
User Name for PPPoE dial-up connection, provided by local ISP.
Null
Password @ PPPoE
Password for PPPoE dial-up connection, provided by local ISP.
Null
Connection Mode @
PPPoE
Select from “Always Online” and “Connect On Demand”.
Always Online: Auto activates PPP and keeps the link up after power on.
Connect On Demand: After selection this option, user could configure
Triggered by Serial Data, Triggered by Periodically Connect and
Triggered by Time Schedule.
Note: If you select several connect on demand polices, router only have
to meet one of them to be triggered.
Always
Online
Redial Interval @
Connect On Demand @
PPPoE
Router will automatically re-dial with this interval when it fails
communicating to peer via TCP or UDP.
30
Retries @ Connect On
Demand @ PPPoE
The maximum retries times for automatically re-connect when router
fails to dial up.
3
Inactivity Time @
Connect On Demand @
PPPoE
This field specifies the idle time setting for PPPoE auto-disconnection.
0 means timeless.
0
Serial Output Content
@ Connect On Demand
@ PPPoE
The content which output to the serial device which connect to router
and inform it that router is ready to receive serial data.
Null
Triggered By Serial Data
@ Connect On Demand
@ PPPoE
Tick this check box to allow router automatically PPPoE dial up from idle
mode when there is data comes out from serial port.
Disable
Periodically Connect @
Connect On Demand @
PPPoE
Tick this check box to allow router automatically PPPoE dial up with
preset interval which you preset in Periodically Connect Interval.
Disable
Periodically Connect
Interval @ Connect On
Demand @ PPPoE
Periodically Connect Interval for Periodically Connect.
300
Time Schedule @
Connect On Demand @
PPPoE
Select the Time Range to allow router automatically connects to cellular
network during this time range.
Null
Time Range @ Connect
On Demand @ PPPoE
Adding the Time Range for Time Schedule. You can set the days of one
week and at most three ranges of time of one day.
Null
Show Advanced Options
@ PPPoE
Tick to enable the PPPoE client advanced setting.
Disable
Service Name @ PPPoE
Set the service name of PPPoE server.
Null
Local IP Address @
PPPoE client will only accept this IP address which was assigned by
Null
