Robustel GoRugged R3000 Quad User Guide
RT_UG_R3000 Quad_v.1.2.0 02.07.2015 64 / 136
Confidential
Note: if user click to enable “Optimize for TCP Flags”, “Optimize for Serial Data
Forwarding”, and “Optimize for ICMP” at the same time (these three services
are in the same priority level), router will automatically start Stochastic Fairness
Queueing (SFQ) strategy to make a fair bandwidth allocation, in case of one
service occupy all the bandwidth.
Optimize for Serial
Data Forwarding
Enable to optimize for serial data forwarding, which means serial data
forwarding will get the highest priority to occupy bandwidth.
When enable serial data forwarding it need to enable local port number for
controlling. Therefore, it needs to set local port number of router even if router
is as TCP Client.
Disable
Priority Percent
Definition
Define priority percent of “Exempt”, “Premium”, “Express”, “Normal” and
“Bulk”.
“Exempt” is defaulted as 50; “Premium” is defaulted as 25; “Express” is
defaulted as 15; “Normal” is defaulted as 10; “Bulk” is 1.
Default Priority
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”. Users
(Services) with no other pre-priority set will use this default priority.
Exempt: this is the highest priority which guarantees that the minimum global
rate of router is 50% of “Downlink Speed”, and the maximum rate can reach to
100% of “Downlink Speed”.
Premium: guarantees that the minimum global rate of router is 25% of
“Downlink Speed”, and the maximum rate can reach to 100% of “Downlink
Speed”.
Express: guarantees that the minimum global rate of router is 15% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal: guarantees that the minimum global rate of router is 10% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Bulk: guarantees that the minimum global rate of router is 1% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal
MAC Address @ QoS
MAC Control List
Enter MAC address of the user (for example, PC) who you want to set it with
QoS Control. Router supports up to 20 users set with QoS MAC Control. Priority
of QoS MAC Control is higher than that of QoS IP control.
Null
Priority @ QoS MAC
Control List
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”.
Select the priority of the user (for example, PC) who you want to set it with QoS
Control.
Exempt: this is the highest priority which guarantees that the minimum global
rate of router is 50% of “Downlink Speed”, and the maximum rate can reach to
100% of “Downlink Speed”.
Premium: guarantees that the minimum global rate of router is 25% of
“Downlink Speed”, and the maximum rate can reach to 100% of “Downlink
Speed”.
Express: guarantees that the minimum global rate of router is 15% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal: guarantees that the minimum global rate of router is 10% of “Downlink
Exempt
