Robustel R1510 User Guide
RT_UG_R1510_v.1.0.1 Dec. 31, 2019 35/140
Indicate the ordinal of the list.
Show the type of the link.
Enter a description for this link. It can be null.
Select from “DHCP”, “Static” or “PPPoE”.
Set the IP address with Netmask which can access the internet.
IP address with Netmask, e.g. 192.168.1.1/24
Set the gateway of the IP address in WAN port.
Enter the username provided by your Internet Service Provider.
Enter the password provided by your Internet Service Provider.
Select from “Auto”, “PAP” or “CHAP” as the local ISP required.
Enter the PPP Expert options used for PPPoE dialup. You can enter some
other PPP dial strings in this field. Each string can be separated by a
semicolon.
Click the toggle button to enable/disable the ping detection mechanism, a
keep-alive policy of the router.
Router will ping this primary address/domain name to check that if the
current connectivity is active.
Router will ping this secondary address/domain name to check that if the
current connectivity is active.
Set the ping retry interval. When ping failed, the router will ping again
every retry interval.
Set the max ping tries. Switch to another link or take emergency action if
To Next Page
