Robustel R1510 User Guide
RT_UG_R1510_v.1.0.1 Dec. 31, 2019 68/140
Filtering
Item
Description
Default
Target Address
Defines if access is allowed to one or a range of IP addresses which are
defined by Target IP Address, or every IP addresses.
Null
Target Port
Enter the target port which the access originator wants to access.
Null
Protocol
Select from “All”, “TCP”, “UDP”, “ICMP” or “TCP-UDP”.
Note: It is recommended that you choose “All” if you don’t know
which protocol of your application to use.
All
Action
Select from “Accept” or “Drop”.
 Accept: When Default Filtering Policy is drop, router will drop all
the connecting requests except the hosts which fit this accept
filtering list
 Drop: When Default Filtering Policy is accept, router will accept all
the connecting requests except the hosts which fit this drop
filtering list
Drop
Port Mapping
Port mapping is defined manually in the router, and the data received from some ports in the public network are all
forwarded to a port of an IP in the internal network. Click "network > firewall > port map" to display as follows:
Click to add port mapping rules. The maximum rule count is 40.
Port Mapping Rules
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Description
Enter a description for this port mapping.
Null
