Robustel R1510 User Guide
RT_UG_R1510_v.1.0.1 Dec. 31, 2019 44/140
4.2.3 Ethernet
This section allows you to set the related parameters for Ethernet. There are two Ethernet ports on R1510 Router,
including ETH0 and ETH1. ETH0 can be configured as the WAN port for the router to access the outer network or the
LAN port for the lower end devices to connect with the router. ETH1 can only be configured as a LAN port for the
lower device to connect to the router. By default, ETH0 and ETH1 are lan0, and their IP are
192.168.0.1/255.255.255.0.
Click the button on the right-most of eth1 to change the port parameters in the port window that pops up.
Port Settings
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Port
Show the editing port, read only.
--
Port Assignment
Choose the Ethernet ports type, as a WAN port or a LAN port. When setting the
port as a LAN port in Interface > LAN > LAN > Network Settings > General Settings,
you can click the drop-down list to select from lan0” or “lan1”.
lan0
