Robustel R1510 User Guide
RT_UG_R1510_v.1.0.1 Dec. 31, 2019 75/140
IKE Settings
Item
Description
Default
IKE Type
Select from “IKEv1” and “IKEv2”.
IKEv1
Negotiation Mode
Select from “Main” and “Aggressive” for the IKE negotiation mode in phase 1.
If the IP address of one end of an IPsec tunnel is obtained dynamically, the IKE
negotiation mode must be aggressive. In this case, SAs can be established as
long as the username and password are correct.
Main
Mode
Encryption Algorithm
Select from “3DES”, “AES128”, “AES192”and “AES256”to be used in IKE
negotiation.
 3DES: Use 168-bit 3DES encryption algorithm in CBC mode
 AES128: Use 128-bit AES encryption algorithm in CBC mode
 AES192: Use 192-bit AES encryption algorithm in CBC mode
 AES256: Use 256-bit AES encryption algorithm in CBC mode
3DES
Authentication
Algorithm
Select from “MD5”, “SHA1”, “SHA2 256” or “SHA2 512” to be used in IKE
negotiation.
SHA1
IKE DH Group
Select from “DHgroup1”,“DHgroup2”, “DHgroup5”, “DHgroup14”,
“DHgroup15”, “DHgroup16”, “DHgroup17” or “DHgroup18” to be used in key
negotiation phase 1.
DHgroup2
Authentication Type
Select from “PSK”, “CA”, “PKCS#12”, “xAuth PSK” and “xAuth CA” to be used
in IKE negotiation.
 PSK: Pre-shared Key
 CA: x509 Certification Authority
 xAuth: Extended Authentication to AAA server
 PKCS#12: Exchange digital certificate authentication
PSK
PSK Secret
Enter the pre-shared key.
Null
Local ID Type
Select from “Default”, “FQDN” and “User FQDN” for IKE negotiation.
 Default: Uses an IP address as the ID in IKE negotiation
 FQDN: Uses an FQDN type as the ID in IKE negotiation. If this option is
selected, type a name without any at sign (@) for the local security
Default
