Robustel R3000-4L User Manual

Robustel GoRugged R3000 User Guide
RT_UG_R3000_v.4.0.0 27 March, 2017 11/136
Confidential
 AC/DC power adapter (12V DC, 1.5 A; EU/US/UK/AU plug optional)
1.3 Specifications
Cellular Interface
 Number of ports: 2 (AUX + MAIN)
 Connector: SMA, female
 Standards: GSM/GPRS/EDGE/UMTS/TD-SCDMA/HSPA+/LTE
GSM: max DL/UL = 9.6/2.7 Kbps
GPRS: max DL/UL = 86 Kbps
EDGE: max DL/UL = 236.8 Kbps
UMTS: max DL/UL = 384 Kbps
TD-SCDMA: max DL/UL = 2.8 Mbps/384 Kbps
HSPA+: max DL/UL = 21/5.76 Mbps, fallback to 2G
FDD LTE: max DL/UL = 100/50 Mbps, fallback to 2G/3G
TDD LTE: max DL/UL = 100/50 Mbps, fallback to 2G/3G
Ethernet Interface
 Number of ports: 2 x 10/100 Mbps, 2 x LAN or 1 x LAN + 1 x WAN
 Magnet isolation protection: 1.5 KV
WLAN port (Optional)
 Number of ports: 1
 Connector: RP-SMA, male
 Standards: 802.11a/b/g/n, supporting AP and Client mode
 Frequency bands: 2.412 - 2.484 GHz (2.4 GHz ISM band), 4.910 – 5.825 GHz (5.8 GHz ISM band)
 Security: Open ,WPA, WPA2, WEP
 Encryption: AES, TKIP, WEP64
 Data speed: Up to 150 Mbps
 Receiving sensitivity: 1 M -97 dBm (< 8% PER)
(+/- 1 dBm) 54 Mbps -76.5 dBm (< 10% PER)
MCS7 (20 MHz) -72 dBm (< 10% PER)
MCS7 (40 MHz) -69 dBm (< 10% PER)
