Robustel GoRugged R3000 User Guide
RT_UG_R3000_v.4.0.0 27 March, 2017 46/136
Confidential
Status
This section allows you to view the status of LAN connection.
Click the row of status, the details status information will be display under the row. Please refer to the screenshot
below.
3.8 Interface > Ethernet
This section allows you to set the related parameters for Ethernet. There are two Ethernet ports on R3000 Router,
including ETH0 and ETH1. The ETH0 on the router can be configured as either a WAN or a LAN port, while ETH1 can
only be configured as a LAN port. By default, ETH0 and ETH1 are lan0, and their IP are 192.168.0.1/255.255.255.0.
Since lan0 must be assigned to one port and WAN port must be assigned to the ETH0, there are four configurations.
You can choose the appropriate configuration to fit your current needs. The specific port configurations are shown
below.
