Robustel GoRugged R3000 User Guide
RT_UG_R3000_v.4.0.0 27 March, 2017 16/136
Confidential
Note: You can choose the display type of USR LED. For more details, please refer to 3.29 Service > Advanced.
2.2 PIN Assignment
100 module found but AT command failed
010 no SIM card inserted110
110 need to enter the PIN code
001 need to enter the PUK code
101 registration failed
011 no module found
111 not support the module
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PIN
Debug
RS-232
Direction
1
CR
--
R3000  Device
2
CT
--
R3000  Device
3
GND
GND
--
4
--
TXD
R3000  Device
5
--
RXD
R3000  Device
6
--
RTS
R3000  Device
7
--
CTS
R3000  Device
PIN
Power
DI/DO
RS-485
Direction
8
Positive
--
--
--
9
Negative
--
--
--
10
GND
--
--
--
11
--
Input 1
--
R3000  Device
12
--
Input 2
--
R3000  Device
13
--
Output 1
--
R3000  Device
14
--
Output 2
--
R3000  Device
15
--
GND
--
--
16
--
--
Data+(A)
R3000  Device
17
--
--
Data- (B)
R3000  Device
