Robustel R3000-4L User Manual

Robustel GoRugged R3000 User Guide
RT_UG_R3000_v.4.0.0 27 March, 2017 34/136
Confidential
Link Settings (WWAN)
Item
Description
Default
WWAN Settings
Automatic APN
Selection
Click the toggle button to enable/disable the “Automatic APN Selection”
option. After enabling, the device will recognize the access point name
automatically. Alternatively, you can disable this option and manually add
the access point name.
ON
APN
Enter the Access Point Name for cellular dial-up connection, provided by
local ISP.
internet
Username
Enter the username for cellular dial-up connection, provided by local ISP.
Null
Password
Enter the password for cellular dial-up connection, provided by local ISP.
Null
Dialup Number
Enter the dialup number for cellular dial-up connection, provided by local
ISP.
*99***1#
Authentication Type
Select from “Auto”, “PAP” or “CHAP” as the local ISP required.
Auto
Aggressive Reset
Click the toggle button to enable/disable this option. When enabled, the
module will be reset if the link cannot access the network.
OFF
Switch SIM By Data
Allowance
Click the toggle button to enable/disable this option. After enabling, it will
switch to another SIM when the data limit reached.
Note: Only used for dual SIM backup.
OFF
Data Allowance
Set the monthly data traffic limitation. The system will record the data
traffic statistics when data traffic limitation (MiB) is specified. The traffic
record will be displayed in Interface > Link Manager > Status > WWAN
Data Usage Statistics. 0 means disable data traffic record.
0
Billing Day
Specify the monthly billing day. The data traffic statistics will be
recalculated from that day.
1
Ping Detection Settings
Enable
Click the toggle button to enable/disable the ping detection mechanism, a
keep-alive policy of R3000 Router.
ON
Primary Server
Router will ping this primary address/domain name to check that if the
current connectivity is active.
8.8.8.8
Secondary Server
Router will ping this secondary address/domain name to check that if the
current connectivity is active.
114.114.11
4.114
Interval
Set the ping interval.
300
Retry Interval
Set the ping retry interval. When ping failed, the router will ping again
every retry interval.
5
Timeout
Set the ping timeout.
3
Max Ping Tries
Set the max ping tries. Switch to another link or take emergency action if
the max continuous ping tries reached.
3
Advanced Settings
NAT Enable
Click the toggle button to enable/disable the Network Address Translation
option.
ON
Upload Bandwidth
Set the upload bandwidth used for QoS, measured in kbps.
10000
Download Bandwidth
Set the download bandwidth used for QoS, measured in kbps.
10000
