Select from “DHCP”, “Static” or “PPPoE”.
Set the IP address with Netmask which can access the internet.
IP address with Netmask, e.g. 192.168.1.1/24
Set the gateway of the IP address in WAN port.
Enter the username provided by your Internet Service Provider.
Enter the password provided by your Internet Service Provider.
Select from “Auto”, “PAP” or “CHAP” as the local ISP required.
Enter the PPP Expert options used for PPPoE dialup. You can enter some
other PPP dial strings in this field. Each string can be separated by a
semicolon.
Click the toggle button to enable/disable the ping detection mechanism, a
keep-alive policy of R3000 Router.
Router will ping this primary address/domain name to check that if the
current connectivity is active.
Router will ping this secondary address/domain name to check that if the
current connectivity is active.
Set the ping retry interval. When ping failed, the router will ping again
every retry interval.
Set the max ping tries. Switch to another link or take emergency action if
the max continuous ping tries reached.
Click the toggle button to enable/disable the Network Address Translation
option.
Enter the Maximum Transmission Unit.
Enter the upload bandwidth used for QoS, measured in kbps.
Enter the download bandwidth used for QoS, measured in kbps.
Override primary DNS will override the automatically obtained DNS.
Override secondary DNS will override the automatically obtained DNS.
Click the toggle button to enable/disable this option. Enable for debugging
information output.
Click the toggle button to enable/disable this option. Enable for verbose
debugging information output.
