Robustel GoRugged R3000 User Guide
RT_UG_R3000_v.4.0.0 27 March, 2017 43/136
Confidential
The window is displayed as below when choosing “Server” as the mode.
The window is displayed as below when choosing “Relay” as the mode.
LAN
Item
Description
Default
DHCP Settings
Enable
Click the toggle button to enable/disable the DHCP function.
ON
Mode
Select from “Server” or “Relay”.
 Server: Lease IP address to DHCP clients which have been
connected to LAN port
 Relay: Router can be DHCP Relay, which will provide a relay
tunnel to solve problem that DHCP Client and DHCP Server is not
in a same subnet
Server
IP Pool Start
Define the beginning of the pool of IP addresses which will be leased
to DHCP clients.
192.168.0.2
