3.7 Interface > LAN
This section allows you to set the related parameters for LAN port. There is one LAN port on R3000 Lite Router, which
is ETH. The default settings of ETH is lan0 and its default IP is 192.168.0.1/255.255.255.0.
LAN
Note: Lan0 cannot be deleted.
You may click to edit the configuration of the LAN port, or click to delete the current LAN port. Now, click to
add a new LAN port.
General Settings @ LAN
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Interface
Lan1 is available only if it was selected by one of ETH1~ETH4 in Ethernet >
Ports > Port Settings, and so on.
lan0
IP Address
Set the IP address of the LAN port.
192.168.0.1
Netmask
Set the Netmask of the LAN port.
255.255.255.0
MTU
Enter the Maximum Transmission Unit.
1500
The window is displayed as below when choosing “Server” as the mode.
