190 Rockwell Automation Publication 1769-UM021I-EN-P - May 2018

Chapter 8 Use I/O Modules with CompactLogix 5370 L2 Controllers

Figure 32 shows an example of 2-wire, 3-wire, and 4-wire RTD/Resistance

wiring diagrams on a 1769-L27ERM-QBFC1B controller.

Figure 32 - 1769-L27ERM-QBFC1B RTD/Resistance Wiring Diagrams

Earth

3-wire Device

Wiring Diagram

4-wire Device

Wiring Diagram

IMPORTANT: For all

wiring diagrams, we

recommend that you

use Belden #83503 or

9533 cable.

2-wire Device

Wiring Diagram
