Rockwell Automation Allen-Bradley 856T-B24LC - Appendix A Specifications; 10-Link Module Specifications

Rockwell Automation Publication 856T-UM001B-EN-P - April 2021 53
Appendix A
Specifications
IO-Link Module
Specifications
Table 9 - 856T-B24LC Module Specifications
Attribute 856T-B24LC
Certifications
•c-UL-us
•CE (EMC and RoHS)
•UKCA
•RCM
•KCC
• Morocco
Vibration According to EN 60068-2-6, EN60721-3-2 Class 2M2. See Table 10 on page 53
.
Shock According to EN60068-2-27. See Table 10 on page 53
.
Status indicator Bicolor (red/green) LED
Operating voltage 18…30V DC per IO-Link specification
Operating current
consumption at 24V DC
30 mA
Inrush current at 24V DC 0.1 A
EMC compliance 60947-5-1 standard
IO-Link Specifications
Communication rate COM3 (230.4 kBd)
IO-Link cycle time, min 2 ms
Process data
• Input bit length: 48 bits (6 Bytes)
• Output bit length: 56 bits (7 Bytes)
IO-Link standard (version) 1.1.2
M12 connector 5-pin, Class B
Mechanical
Material
• Housing and Cover: Polycarbonate
•M12 connector: Nylon
• Connector O-rings: Silicone
(1)
• IO-Link module O-ring: Nitrile rubber
(1) The O-ring was tested to be well below 1% by weight when tested according to GMW17224 (Test for Volatiles in Silicone
Rubber).
Weight 0.157 kg (0.346 lb)
Dimensions
• Height: 65.1 mm (2.56 in.)
• Diameter: 70 mm (2.8 in.)
Environmental
Ingress protection rating IP66/67, UL Type 4/4X/13
Operating temperature -30…+70 °C (-22…+158 °F)
Storage temperature -30…+85 °C (-22…+185 °F)
Relative humidity 90% (noncondensing)
Reliability
MTTF 41,600 hr
Table 10 - 856T-B24LC Module Shock and Vibration Specifications
Attribute Shock, Peak [G] Vibration, Peak [G]
Surface mount base (seven modules stacked) 20 3
Surface mount base (five modules stacked, max) 30 3
Vertical mount base 50 3
10 cm pole/tube base 50 3
25 cm pole/tube base 50 3
40 cm pole base 50 3
60 cm pole base 50 3
