Rockwell Automation Allen-Bradley 856T-B24LC - Parameter Tab

Rockwell Automation Publication 856T-UM001B-EN-P - April 2021 61
Appendix C Device Parameters
Parameter Tab
X-axis average vibration 0x0142/322 0x0001/1 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 32)
Y-axis average vibration 0x0142/322 0x0002/2 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 16)
Z-axis average vibration 0x0142/322 0x0003/3 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 0)
Max Vibration since
power up
0x0145/325 — Read-only — 0…16,000
RecordT
(bit length = 48)
X-axis Max Vibration
since power up
0x0145/325 0x0001/1 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 32)
Y-axis Max Vibration
since power up
0x0145/325 0x0002/2 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 16)
Z-axis Max Vibration
since power up
0x0145/325 0x0003/3 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 0)
Max Vibration Lifetime 0x014F/335 — Read-only — 0…16,000
RecordT
(bit length = 48)
X-axis Max vibration
Lifetime
0x014F/335 0x0001/1 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 32)
Y-axis Max vibration
Lifetime
0x014F/335 0x0002/2 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 16)
Z-axis Max vibration
Lifetime
0x014F/335 0x0003/3 Read-only — 0…16,000
IntegerT
(bit length = 16,
bit offset = 0)
Table 14 - Observation Tab (Continued)
Parameter Name
Index
(Hex/Dec)
Sub Index
(Hex/Dec)
Access Default Value Allowed Value
Data Type
(Length, Offset)
Table 15 - Parameter Tab
Parameter Name
Index
(Hex/Dec)
Sub Index
(Hex/Dec)
Access Default Value Allowed Value
Data Type
(Length, Offset)
Module Type 0x0138/312 — Read/write 0 0…11
RecordT
(bit length = 56)
. Module 1 Type 0x0138/312 0x0001/1 Read/write 0
0= No Module
1=856T Steady Light
2=856T Multi-function Modules
3=856T Rotating Light Module
4=856T Multi-color Light Module
5=856T Steady/Flashing beacon
6=856T Strobe beacon
7=856T Rotating beacon
8=856T Multi-color beacon
9=856T Piezo Electric Sounder
10=856T Transducer Sounder
11=856T Recordable Sound Module
Uinteger
(bit length = 8,
bit offset = 48)
. Module 2 Type 0x0138/312 0x0002/2 Read/write 0
0= No Module
1=856T Steady Light
2=856T Multi-function Modules
3=856T Rotating Light Module
4=856T Multi-color Light Module
5=856T Steady/Flashing beacon
6=856T Strobe beacon
7=856T Rotating beacon
8=856T Multi-color beacon
9=856T Piezo Electric Sounder
10=856T Transducer Sounder
11=856T Recordable Sound Module
Uinteger
(bit length = 8,
bit offset = 40)
