18 Rockwell Automation Publication 1756-UM542A-EN-P - September 2014
Chapter 3 Operation
Table 3 - Logix5000 Controller Input Image Parameters
Parameter Description Value
CommStatus Reserved. –
Source Indicates the current time source. 1 = GPS
2 = IRIG-B
3 = PTP
4 = NTP
5 = External GPS (future)
6 = Simulation
ModuleStatus Reserved. –
WebserverEnable Allows you to access the web server from a web browser pointed to
the
IP address of the module.
0 = Module does not allow access to the web server
1 = Module allows access to the web server
Time.TimeValid Indicates if a valid time is being received from the time source. 0 = Time being received from source is invalid
1 = Time being received from source is valid
Time.CIPSyncOutputEnable Indicates if the 1588 Output PTP is enabled in the configuration. 0 = 1588 PTP (CIP Sync) output is disabled
1 = 1588 PTP (CIP Sync) output is enabled
Time.NTPOutputEnable Indicates if the NTP Output is enabled in the configuration. 0 = NTP v3 RF(1305) output is disabled
1 = NTP v3 RF(1305) output is enabled
Time.IRIGBOutputEnable Indicates if the IRIG-B Output is enabled in the configuration. 0 = IRIG-B-122 output is disabled
1 = IRIG-B-122 output is enabled
Time.CSTMasterEnabled Indicates if the module is enabled to be the CST master clock. 0 = Module does not attempt to be the CST master clock
1 = Module does attempt to be the CST master clock
Time.CSTMastership Indicates if the module is the CST master clock on the local rack. 0 = Module is not the CST master clock
1 = Module is the CST master clock
Time.CSTDuplicateDetect Indicates if the module is attempting to be the CST master clock.
If there is another CST master clock on the local rack, the module sets
this bit and stops attempting to be the CST master clock.
0 = There is no other CST master clock on the local rack
1 = There is another CST master clock on the local rack
Time.SimulationModeActive Indicates if the module is operating in simulation mode. 0 = Simulation mode is inactive
1 = Simulation mode is active
Time.Year Displays the current year received from the time source. Example:
27/04/2010
13:45:22 - 234567 μs
Year = 2010
Time.Month Displays the current month received from the time source. Example:
27/04/2010
13:45:22 - 234567 μs
Month = 4
Time.Day Displays the current day received from the time source. Example:
27/04/2010
13:45:22 - 234567 μs
Day = 27
Time.Hour Displays the current hour received from the time source. Example:
27/04/2010
13:45:22 - 234567 μs
Hour = 13
Time.Minute Displays the current minute received from the time source. Example:
27/04/2010
13:45:22 - 234567 μs
Minute = 45
