Preface
Time synchronization is accomplished by using these methods, standards, and
protocols:
• The
ControlLogix® backplane for Coordinated System Time (CST) and
Coordinated Universal Time (UTC) conversion.
• Inter-range Instrumentation Group, code B (IRIG-B) standards.
• Precision Time Protocol (PTP) on Ethernet and the ControlLogix
backplane.
• Network Time Protocol (NTP) on Ethernet.
The 1756HP-TIME module provides GPS position in the form of latitude,
lon
gitude, and altitude (LLA).
The 1756HP-TIME module provides course and route information in the form
of g
round speed (knots) with heading in the form of degrees from true north.
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at
http:/www.rockwellautomation.com/literature/. To order paper copies of
technical documentation, contact your local Allen-Bradley distributor or
R
ockwell Automation sales representative.
Resource Description
Integrated Architecture and CIP Sync Configuration
Application Technique, publication IA-AT003
This document explains CIP sync technology and how
you can synchronize clocks within the Rockwell
Automation Integrated Architecture.
ControlLogix System User Manual, publication 1756-UM001 Describes the necessary tasks to install, configure,
program, and operate a ControlLogix system.
EtherNet/IP Network Configuration User Manual,
publication
ENET-UM001
Provides Bootstrap Protocol/ Dynamic Host
Configuration Protocol (BOOTP/DHCP) information for
setting the IP address of the module.
ControlFLASH® Firmware Upgrade Software User Manual,
publication 1756-UM105
Describes the necessary tasks to install, and use the
ControlFLASH software to update the module firmware.
Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
Provides general guidelines for installing a Rockwell
Automation industrial system.
Product Certifications website,
http://www.ab.com Provides declarations of conformity, certificates, and
other certification details.
