Rockwell Automation Publication 1756-UM542A-EN-P - September 2014 31
Appendix A
Specifications
Technical Specifications
This table lists the technical specifications for the 1756HP-TIME module.
Cable Specifications
This table lists the cable specifications for the 1756HP-TIME module.
Topic Page
Technical Specifications 31
Cable Specifications 31
GPS Antenna Specifications 32
Dimensions 33
Attribute Value
Power requirements All power is derived from the 1756 backplane.
Current draw at 5V = 736 mA
Current draw at 24V = 1.64 mA
Power consumption
Operating temperature
0…50 °C (32…122 °F)
Storage temperature
Relative humidity 5… 95% noncondensing
Enclosure type rating IP20
Ethernet conductor CAT5 STP
Attribute Value
Cable type Type RG58 or equivalent
Impedance 50 Ω
Shield Foil or copper braid (100% coverage)
Connectors SMA male to TNC male
Signal attenuation At 1.5 GHz < 10 dB (less than 6 dB recommended)
