Rockwell Automation Allen-Bradley ControlLogix B Series

Rockwell Automation Publication 1756-UM542A-EN-P - September 2014 33
Specifications Appendix A
Dimensions
This drawing shows the dimensions of the 1756HP-TIME module.
35 mm (1.37 in.)
140 mm (5.51 in.)
153 mm (6.02 in.)
1756HP-TIME Module PTP, NTP, and IRIG-B Time Master
