Rockwell Automation Publication 1756-UM542A-EN-P - September 2014 17
Chapter 3
Operation
Logix5000 Controller Input
Each 1756HP-TIME module consumes one connection from the Logix5000
controller. This section provides descriptions for the Logix5000 controller input
image parameters.
Topic Page
Logix5000 Controller Input Image 17
Logix5000 Controller Output Image 20
Web Interface 21
