Rockwell Automation Publication 1756-UM542A-EN-P - September 2014 37
Appendix C
CST/UTC Conversion Message Blocks
CST to UTC and Gregorian
Time Conversion
This table shows the structure of the message block for the CST to UTC and
Gregorian time conversion.
UTC to Gregorian Time
Conversion
This table shows the structure of the message block for the UTC to Gregorian
time conversion.
Topic Page
CST to UTC and Gregorian Time Conversion 37
UTC to Gregorian Time Conversion 37
Satellite Information 38
Settings and Elements Attribute Value
Message settings
Message type CIP generic
Service type Custom
Service code 36h
Class 72h
Instance 01h
Attribute 03h
Date elements
Source element Event_CST[0]
(1)
(1) See the example code at http://www.hiprom.com/.
Source length 8
Destination Event.Year
(1)
Settings and Elements Attribute Value
Message settings
Message type CIP generic
Service type Custom
Service code 36h
Class 72h
Instance 01h
Attribute 04h
Date elements
Source element Event_UTC[0]
(1)
(1) See the example code at http://www.hiprom.com/.
Source length 8
Destination Event.Year
(1)
