Appendix D
Operating Modes
GPS Source
The GPS source mode can have the following configurations:
• So
urce: GPS
• Outputs: IRIG-B, 1588 PTP/CIP Sync, NTP, and input/output
assemblies.
Topic Page
GPS Source 39
IRIG-B Source 40
PTP Source 40
NTP Source 41
IRIG-B
1588 PTP
NTP
