Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 157
Chapter 10
Using microSD Cards
This chapter provides a description of microSD card support on Micro830,
Micro850, and Micro870 controllers.
The last section provides quickstart projects for the data log and recipe
functions.
Overview With firmware revision 12.011 or later, Micro830, Micro850, and Micro870
controllers support microSD cards through the use of the microSD card plug-
in (a PartnerNetworkâ„¢ Technology partner product) for Micro800 controllers
for the following purposes:
• Project backup and restore
• Data log and Recipe
We recommend using the Allen-Bradley 2080-SD-2GB microSD card.
Topic Page
Overview 157
Project Backup and Restore 158
Backup and Restore Directory Structure 159
Power-up Settings in ConfigMeFirst.txt 160
General Configuration Rules in ConfigMeFirst.txt 162
ConfigMeFirst.txt Errors 162
Data Log 164
Recipe 169
Quickstart Projects for Data Log and Recipe Function Blocks 172
IMPORTANT
For optimum performance, the microSD card should not be more than 90%
full. Regularly check available space on your microSD card and ensure that
the card is exclusively used for the Micro800 controller and no unnecessary
files are present. Regularly delete old data log files and directories.
IMPORTANT
Do not remove the microSD card or power down while operations such as
upload, download, delete, search, backup, and restore are ongoing to
prevent data loss. A blinking SD status LED indicates that these operations
are ongoing.
Note the following:
• The SD status LED will not blink when flash upgrading the firmware from the
microSD card.
• The SD status LED does not blink continuously for the entire duration of the
restore operation.
