Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 39
Chapter 3 Install Your Controller
DIN Rail Mounting
The module can be mounted using the following DIN rails: 35 x 7.5 x 1 mm
(EN 50 022 - 35 x 7.5).
Before mounting the module on a DIN rail, use a flat-blade screwdriver in the
DIN rail latch and pry it downwards until it is in the unlatched position.
1. Hook the top of the DIN rail mounting area of the controller onto th
e
DIN
rail, and then press the bottom
until the controller snaps onto the
DIN
rail.
2. Push the DIN rail latch back into the latched position.
Use DIN rail end anchors (Allen-Bradley part number 1492-EAJ35 or 1492-
EAHJ35) for vibration or shock environments.
To remove your controller from the DIN rail, pry the DIN rail latch downwards
until it is in the unlatched position.
Panel Mounting
The preferred mounting method is to use four M4 (#8) screws per module.
Hole spacing tolerance: ±0.4 mm (0.016 in.).
Follow these steps to install your controller using mounting screws.
1. Place the controller against the pane
l where you are mounting it. Make
sure the controller is space
d properly.
2. Mark drilling holes through the mounting screw holes and mounting feet
then remove the controller.
3. Drill the holes at the markings, then replace the controller and mount it.
Leave the protective debris strip in place until you are finished wiring the
controller and any other devices.
For environments with greater vibration and shock concerns, use the panel
mounting method, instead of DIN rail mounting.
IMPORTANT
For instructions on how to install your Micro800 system with expansion I/O,
see Micro800 Expansion I/O Modules User Manual, publication 2080-UM003.
