198 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Appendix A Specifications
Micro850 48-point Controllers
General Specifications — Micro850 48-point Controllers
Attribute 2080-LC50-48AWB 2080-LC50-48QWB 2080-LC50-48QVB 2080-LC50-48QBB
Number of I/O 48 (28 inputs, 20 outputs)
Dimensions (HxWxD) 90 x 238 x 80 mm (3.54 x 9.37 x 3.15 in.)
Shipping weight, approx. 0.725 kg (1.60 lb)
Wire size
0.2…2.5 mm
2
(24…14 AWG) solid copper wire or
0.2…2.5 mm
2
(24…14 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
2 – on communication ports
Wire type Use copper conductors only
Terminal screw torque
0.4…0.5 N•m (3.5…4.4 lb•in)
(using a 0.6 x 3.5 mm flat-blade screwdriver)
Input circuit type 120V AC
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay
24V DC sink
(standard and high-speed)
24V DC source
(standard and high-speed)
Power consumption, max
11 W – without plug-in modules and expansion I/O modules
33 W – with plug-in modules and expansion I/O modules
Power supply voltage range 21.4…26.4V DC Class 2
I/O rating
Input:
120V AC, 16 mA
Output:
2 A, 240V AC,
2 A, 24V DC
Input:
24V, 8.8 mA
Output:
2 A, 240V AC,
2 A, 24V DC
Input:
24V, 8.8 mA
Output:
24V DC, 1 A per point
(surrounding air temperature 30 °C)
24V DC, 0.3 A per point
surrounding air temperature 65 °C)
Insulation stripping length 7 mm (0.28 in)
Enclosure type rating Meets IP20
Pilot duty rating C300, R150 –
Isolation voltage
250V (continuous), Reinforced
Insulation Type, Output to Aux
and Network, Inputs to Outputs.
Type tested for 60 s @ 3250V DC
Output to Aux and Network,
Inputs to Outputs.
150V (continuous), Reinforced
Insulation Type Input to Aux and
Network
Type tested for 60 s @ 1950V DC
Input to Aux and Network.
250V (continuous), Reinforced
Insulation Type, Output to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 3250V DC
Output to Aux and Network,
Inputs to Outputs
50V (continuous), Reinforced
Insulation Type, Input to Aux and
Network
Type tested for 60 s @ 720V DC,
Inputs to Aux and Network
50V (continuous), Reinforced Insulation Type, I/O to Aux and Network,
Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network, Inputs to
Outputs.
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
