48 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Chapter 4 Wire Your Controller
Grounding the Controller This product is intended to be mounted to a well grounded mounting surface
such as a metal panel. See the Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1
, for additional information.
Bulletin 100C, (C09…C97)
24…48V AC
100-FSC48
(1)
RC110…280V AC
100-FSC280
(1)
380…480V AC
100-FSC480
(1)
12…55V AC, 12…77V DC
100-FSV55
(1)
MOV
56…136V AC, 78…180V DC
100-FSV136
(1)
137…277V AC, 181…250V DC
100-FSV277
(1)
278…575V AC
100-FSV575
(1)
12…250V DC
100-FSD250
(1)
Diode
Bulletin 509 Motor Starter Size 0...5
12…120V AC 599-K04
MOV
240…264V AC 599-KA04
Bulletin 509 Motor Starter Size 6
12…120V AC
199-FSMA1
(2)
RC
12…120V AC
199-GSMA1
(3)
MOV
Bulletin 700 R/RM Relay
AC coil Not Required
24…48V DC 199-FSMA9
MOV50…120V DC 199-FSMA10
130…250V DC 199-FSMA11
Bulletin 700 Type N, P, PK, or PH Relay
6…150V AC/DC 700-N24 RC
24…48V AC/DC 199-FSMA9
MOV50…120V AC/DC 199-FSMA10
130…250V AC/DC 199-FSMA11
6…300V DC 199-FSMZ-1 Diode
Miscellaneous electromagnetic devices limited to 35
sealed VA
6…150V AC/DC 700-N24 RC
(1) Catalog numbers for screwless terminals include the string ’CR’ after ’100-’. For example: Cat. No. 100-FSC48 becomes Cat. No. 100-CRFSC48; Cat. No. 100-FSV55 becomes 100-CRFSV55; and so on.
(2) For use on the interposing relay.
(3) For use on the contactor or starter.
(4) RC Type not to be used with Triac outputs. Varistor is not recommended for use on the relay outputs.
Recommended Surge Suppressors (Continued)
Device Coil Voltage Suppressor Catalog Number
Type
(4)
WARNING: All devices connected to the RS-232/RS-485 communication port
must be referenced to controller ground, or be floating (not referenced to a
potential other than ground). Failure to follow this procedure may result in
property damage or personal injury.
