188 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Appendix A Specifications
Output circuit type Relay
12/24V DC sink transistor (standard and
high-speed)
Event input interrupt support Yes
Power consumption, max
5 W – without plug-in modules
7.88 W – with plug-in modules
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating
Input:
120V AC, 16 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
24V DC, 1 A per point
(Surrounding air temperature 30 °C)
24V DC, 0.3 A per point
(Surrounding air temperature 65 °C)
Isolation voltage
250V (continuous), Reinforced Insulation
Type, Outputs to Aux and Network, Inputs to
Outputs
Type tested for 60 s @ 3250V DC I/O to Aux
and Network, Inputs to Outputs
250V (continuous), Reinforced Insulation
Type, Outputs to Aux and Network, Inputs to
Outputs
Type tested for 60 s @ 720V DC, Inputs to
Aux and Network, 3250V DC Outputs to Aux
and Network, Inputs to Outputs
50V (continuous), Reinforced Insulation Type,
I/O to Aux and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux
and Network, Inputs to Outputs
Pilot duty rating C300, R150 –
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
General Specifications — Micro830 16-point Controllers (Continued)
Attribute 2080-LC30-16AWB 2080-LC30-16QWB 2080-LC30-16QVB
Inputs — Micro830 16-point Controllers
Attribute
2080-LC30-16AWB 2080-LC30-16QVB, 2080-LC30-16QWB
120V AC Input High-Speed DC Input (Inputs 0…3) Standard DC Input (Inputs 4…9)
Number of Inputs 10 4 6
Input group to backplane
isolation
Verified by the following dielectric tests: 1,400V AC for 2 s
132V working voltage (IEC Class 2 reinforced insulation)
Verified by the following dielectric tests: 1,414V DC for 2 s
75V DC working voltage (IEC Class 2 reinforced insulation)
Voltage category 110V AC 24V DC sink/source
On-state voltage range
79…132V AC
47…63 Hz
16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 20V AC 5V DC
Off-state current, max 1.5 mA
On-state current, min 5 mA @ 79V AC 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 12 mA @ 120V AC 7.66 mA @ 24V 6.15 mA @ 24V
On-state current, max 16 mA @ 132V AC 12.0 mA @ 30V DC
Nominal impedance
12 kΩ @ 50 Hz
10 kΩ @ 60 Hz
3 kΩ 3.74 kΩ
Inrush current, max 250 mA @ 120V AC —
Turn on time/
Turn off time, max
(without filtering)
ON: 1 ms
OFF: 8 ms
ON: 3.2 µs
OFF: 0.6 µs
ON: 33 µs…0.1 ms
OFF: 22 µs…0.02 ms
IEC input compatibility Type 3
AC input filter setting
8 ms for all embedded inputs
(In Connected Components Workbench software, go to the Embedded I/O configuration window to reconfigure the filter setting for each input
group)
