190 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Appendix A Specifications
Wire size
0.2…2.5 mm
2
(24…14 AWG) solid copper wire or
0.2…2.5 mm
2
(24…14 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use copper conductors only
Terminal screw torque, max
0.6 Nm (4.4 lb-in)
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay
24V DC sink
(standard and high-speed)
24V DC source
(standard and high-speed)
Event input interrupt support Yes
Power consumption, max
8 W – without plug-in modules
12.32 W – with plug-in modules
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating
Input:
24V DC, 8.8 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
24V DC, Class 2, 1 A per point (Surrounding air temperature 30 °C)
24V DC, Class 2, 0.3 A per point (Surrounding air temperature 65 °C)
Isolation voltage
250V (continuous), Reinforced Insulation Type,
Outputs to Aux and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, Inputs to Aux
and Network, 3250V DC Outputs to Aux and
Network, Inputs to Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network, Inputs to Outputs
Pilot duty rating C300, R150 (2080-LC30-24QWB only) —
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
General Specifications — Micro830 24-point Controllers (Continued)
Attribute 2080-LC30-24QWB 2080-LC30-24QVB 2080-LC30-24QBB
Inputs — Micro830 24-point Controllers
Attribute
2080-LC30-24QWB, 2080-LC30-24QVB, 2080-LC30-24QBB
High-Speed DC Input (Inputs 0…7) Standard DC Input (Inputs 8 and higher)
Number of Inputs 8 6
Voltage category 24V DC sink/source
Operating voltage range 16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 5V DC
Off-state current, max 1.5 mA
On-state current, min 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 12.0 mA @ 30V DC
Nominal impedance 3 kΩ 3.74 kΩ
IEC input compatibility Type 3
AC input filter setting
8 ms for all embedded inputs
(In Connected Components Workbench software, go to the Embedded I/O configuration
window to reconfigure the filter setting for each input group)
