192 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Appendix A Specifications
Wire size
0.2…2.5 mm
2
(24…14 AWG) solid copper wire or
0.2…2.5 mm
2
(24…14 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use copper conductors only
Terminal screw torque, max
0.6 N•m (4.4 lb•in)
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 120V AC
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay
24V DC sink
(standard and high-speed)
24V DC source
(standard and high-speed)
Event input interrupt support Yes, inputs 0…15 only
Power consumption, max
11 W – without plug-in modules
18.2 W – with plug-in modules
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating
Input:
120V AC, 16 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
24V DC, 1 A per point
(Surrounding air temperature 30 °C)
24V DC, 0.3 A per point
(Surrounding air temperature 65 °C)
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
Pilot duty rating C300, R150 —
Isolation voltage
250V (continuous), Reinforced
Insulation Type, Outputs to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 3250V DC
I/O to Aux and Network, Inputs to
Outputs
250V (continuous), Reinforced
Insulation Type, Outputs to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC,
Inputs to Aux and Network,
3250V DC Outputs to Aux and
Network, Inputs to Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux and Network,
Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network, Inputs to
Outputs
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. See Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
General Specifications — Micro830 48-point Controllers (Continued)
Attribute 2080-LC30-48AWB 2080-LC30-48QWB 2080-LC30-48QVB 2080-LC30-48QBB
Inputs — Micro830 48-point Controllers
Attribute
2080-LC30-48AWB 2080-LC30-48QWB, 2080-LC30-48QVB, 2080-LC30-48QBB
120V AC Input High-Speed DC Input (Inputs 0…11) Standard DC Input (Inputs 12 and higher)
Number of Inputs 28 12 16
Voltage category 110V AC 24V DC sink/source
Operating voltage 132V, 60 Hz AC, max 16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 20V AC 5V DC
Off-state current, max 1.5 mA 1.5 mA
On-state current, min 5 mA @ 79V AC 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 12 mA @ 120V AC 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 16 mA @ 132V AC 12.0 mA @ 30V DC
Nominal impedance
12 kΩ @ 50 Hz
10 kΩ @ 60 Hz
3 kΩ 3.74 kΩ
IEC input compatibility Type 3
