210 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Appendix A Specifications
Supply power 24V DC, 1.6 A
Inrush current, max
24 A @ 132V for 10 ms
40 A @ 263V for 10 ms
Power consumption
(Output power)
38.4 W @ 100V AC,
38.4 W @ 240V AC
Power dissipation
(Input power)
45.1 W @ 100V AC,
44.0 W @ 240V AC
Isolation voltage
250V (continuous), Primary to Secondary: Reinforced Insulation Type
Type tested for 60 s @ 2300V AC primary to secondary and 1480V AC primary to
earth ground.
Output ratings, max 24V DC, 1.6 A, 38.4 W
Enclosure type rating Meets IP20
Wire size
0.32...2.1 mm² (22...14 AWG) solid copper wire or
0.32...1.3 mm² (22...16 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Terminal screw torque
0.5…0.6 N•m (4.4…5.3 lb•in)
(using a Phillips-head or 2.5 mm (0.10 in.) flat-blade screwdriver)
Wiring category
(2)
2 – on power ports
Insulation stripping length 7 mm (0.28 in.)
North American temp code T4A
(1) Any fluctuation in voltage source must be within 85...264V. Do not connect the adapter to a power source that has fluctuations
outside of this range.
(2) Use this Conductor Category information for planning conductor routing. See Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1
.
General Specifications — Micro800 External AC Power Supply (Continued)
Attribute Value
