Chapter 2 Programming and Parameters
783 In Posit Dwell
Position error must be within the value specified by Par 782 [In Posit BW] for this amount of time before the In
Position detector sets bit 10 “In Position” of Par
741 [Position Status]. A momentary out-of-position indication
will reset the internal timer and clear the In Position status bit.
Default:
Min/Max:
Units:
0.0040
0.0000/10.0000
s
Y
RW Real
784 Posit Dect1 In
Provides the input variable for Position Watch 1. Position Watch 1 is enabled and configured with Par 740
[Position Control] bits 16 & 17. Position Watch 1 compares this value with Par
780 [PositDetct1 Stpt] and sets bit
8 “Posit Watch1” of Par
741 [Position Status] when the appropriate condition is satisfied. A default link connects
this parameter to Par
763 [Position Actual].
Default:
Min/Max:
0
-/+2147483648
Y
RW 32-bit
Integer
785 Posit Dect2 In
Provides the input variable for Position Watch 2. Position Watch 2 is enabled and configured with Par 740
[Position Control] bits 18 & 19. Position Watch 2 compares this value with Par
781 [PositDetct2 Stpt] and sets bit
9 “Posit Watch2” of Par
741 [Position Status] when the appropriate condition is satisfied. A default link connects
this parameter to Par
763 [Position Actual].
Default:
Min/Max:
0
-/+2147483648
Y
RW 32-bit
Integer
786 Xsync Status
Bit 0 “Sync Pulse” will go high for 0.5ms latching the Sync Generator inputs to the Sync Generator outputs. The period at which this bit is set is determined by Par 787 [Xsync Gen Period].
Note: Bit 1 was changed to “Reserved” for firmware version 2.004.
787 Xsync Gen Period
Sets the period for the Sync Pulse Generator. Bit 0 of Par 786 [Xsync Status] will be set for 0.5 msec and will be
cleared for 0.5msec x 2[Xsync Gen Period] - 0.5 msec.
Note: Values 5 - “16 msec” and 6 - “32 msec” were added for firmware version 2.004.
Default:
Options:
1 =
0 =
1 =
2 =
3 =
“1 msec”
“0.5 msec” 4 = “8 msec”
“1 msec” 5 = “16 msec”
“2 msec” 6 = “32 msec”
“4 msec”
788 Xsync In 1
32-bit integer input of the Sync Generator. Latched to Par 789 [Xsync Out 1]. Link any 32-bit integer parameter to
this input parameter.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
Y
RW 32-bit
Integer
789 Xsync Out 1
Sync Generator 32-bit output register. Latched to Par 788 [Xsync In 1] every time bit 0 “Sync Pulse” of Par 786
[Xsync Status] is set.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
RO 32-bit
Integer
790 Xsync In 2
32-bit integer input of the Sync Generator. Latched to Par 791 [Xsync Out 2]. Link any 32-bit integer parameter to
this input parameter.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
Y
RW 32-bit
Integer
791 Xsync Out 2
Sync Generator 32-bit output register. Latched to Par 790 [Xsync In 2] every time bit 0 “Sync Pulse” of Par 786
[Xsync Status] is set.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
RO 32-bit
Integer
792 Xsync Out 2 Dly
Displays data of Par 791 [Xsync Out 2] from the last sync period.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
RO 32-bit
Integer
793 Xsync In 3
32-bit integer input of the Sync Generator. Latched to Par 794 [Xsync Out 3]. Link any 32-bit integer parameter to
this input parameter.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
Y
RW 32-bit
Integer
794 Xsync Out 3
Sync Generator 32-bit output register. Latched to Par 793 [Xsync In 3] every time bit 0 “Sync Pulse” of Par 786
[Xsync Status] is set.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
Y
RW 32-bit
Integer
795 Xsync Out 3 Dly
Displays data of Par 794 [Xsync Out 3] from the last sync period.
Note: This parameter was changed to an unsigned integer data type and linkable to parameters that are either
real or integer values for firmware version 4.001.
Default:
Min/Max:
0
0/4294967295
Y
RW 32-bit
Integer
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Sync Unstbl Sync Loss InterpInSync Reserved Sync Pulse
Default xxxxxxxxxxxxxxxxxxxxxxxxxxx000x0
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
