Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 59
Programming and Parameters Chapter 2
270 Reslvr0 TP Sel
Enter or write a value to select Fault data displayed in Par 271 [Reslvr0 TP Data].
Default:
Options:
0 =
0 =
1 =
2 =
3 =
“Zero”
“Zero” 4 = “R0 EPR”
“R0 Edge Time” 5 = “R0 Edge Mode”
“R0 dEdge” 6 = “R0 nMax”
“R0 dTime” 7 = “R0 Delta2Err”
271 Reslvr0 TP Data
Displays the data selected by Par 270 [Reslvr0 TP Sel].
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
272 Reslvr0 SpdRatio
Specifies the speed ratio for the resolver option card port 0. The speed ratio comes from the following formula.
Speed ratio = electrical revolutions / mechanical revolutions = pole count / 2.
Note: Option 0 = “Zero” was added for firmware version 2.004.
Default:
Options:
1 =
0 =
1 =
2 =
2 poles (x1)
“Zero” 3 = 6 Poles (x3)
2 Poles (x1) 4 = 8 Poles (x4)
4 Poles (x2) 5 = 10 Poles(x5)
273 Reslvr0 Carrier
Specifies the resolver carrier frequency for the resolver option card port 0.
Default:
Min/Max:
Units:
0
0/10000
Hz
RO 32-bit
Integer
274 Reslvr0 In Volts
Specifies the resolver input voltage for the resolver option card port 0.
Default:
Min/Max:
Units:
0.0000
0.0000/31.0810
V
RO Real
275 Rslvr0 XfrmRatio
Specifies the resolver transform ratio for the resolver option card port 0.
Default:
Min/Max:
0.0000
0.0000/4.0950
RO Real
276 Reslvr0 CableBal
Specifies the resolver cable balance for the resolver option card port 0.
Default:
Min/Max:
0
0/255
RO Real
277 Reslvr0 Type Sel
Specifies used resolver.
The values for options 5 & 12 were changed to “Reserved” for firmware version 2.004. Added options 15 and 16
for firmware version 4.001 but are not functional (for future use).
Default:
Options:
0 =
0 =
1 =
2 =
3 =
4 =
5 =
6 =
7 =
8 =
“Disabled”
“Disabled” 9 = “1326Ax 460v”
“T2014/2087x1” 10 = “Reserved”
“T2014/2087x2” 11 = “Reserved”
“T2014/2087x5” 12 = “Reserved”
“MPL 460v” 13 = “Reserved”
“Reserved” 14 = “AmciR11XC107”
“Siemens 1FT6” 15 = “PowerTec R1”
“PrkrHn ZX600” 16 = “PowerTec R2”
“Reserved”
No. Name
Description
Values
Linkable Read-Write Data Type
