Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

58 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
268 Resolver0 Cnfg
Configures options for the resolver option card port 0.
• Setting bit 0 “Cable Tune” enables the cable tuning test, resetting the bit to zero disables the test. Refer to the section on Resolver Cable Tuning Tests in publication PFLEX-RM003, Reference
Manual - PowerFlex 700S Drives with Phase II Control for more information.
• Bit 1 “Tune Param” has been disabled.
• Bits 2 “Resolution 0” and 3 “Resolution 1” select the resolver resolution (see Table 268A: Resolution Settings
). This determines the number of significant bits that are calculated in the value of Par
250 [FB Opt0 Posit]. It does not affect the number of counts created per resolver revolution (see Table 268B: Resolution and Least Significant Bits Used). Also, the resolution sets a limit on the
maximum tracking speed (see Table 268C: Resolution and Resolver Tracking Speed
).
• Setting bit 4 “Energize” energizes the resolver, resetting the bit to zero de-energizes the resolver.
• Bit 5 “Resolver Dir” determines counting direction. If clear, direction is forward or up. If set, the direction is reverse or down.
1. Bit 9 “Edge Time” configures the method of sampling used by the Velocity Position Loop (VPL). Setting the bit chooses "Edge to Edge" sampling, while resetting the bit to
zero chooses "Simple Difference" sampling. "Simple Difference" sampling calculates speed by examining the difference between pulse counts over a fixed sample time.
"Edge to Edge" sampling adjusts the sample time to synchronize with the position count updates from the daughter card - improving the accuracy of the speed calculation.
• Bits 10 “SmplRate bt0” through 12 “SmplRate bt2” configure the Finite Impulse Response (FIR) Filter (see Table 268D: FIR Filter Settings). This setting reduces the effect of noisy feedback on the
system. Refer to the Speed/Position Feedback section of the PowerFlex® 700S with Phase II Control Reference Manual, publication PFLEX-RM003 for details.
Note: Bit 11 “SmplRate bt0” is set to 0 = False by default for firmware version 1.11 and bit 11 “SmplRate1” is set to 1 = True by default for firmware version 2.003.
269 Resolver0 Status
Indicates status of the resolver option card port 0.
•Bit 0 “-Cable Tune”
• Bit 1 “-Tune Result” indicates the tuning Parameter type. When set, it indicates the tuning is using the parameter database. When cleared, it indicates the tuning is using derived data.
• Bit 2 “-Mtr Turning” indicates that the motor is turning.
• Bit 4 “Energized” indicates the resolver is energized.
• Bit 8 “Open Wire” indicates a problem with the cable (open circuit).
• Bit 9 “Power Supply” indicates problem with the option card's power supply.
• Bit 10 “Diag Fail” indicates the option card has failed its power-up diagnostics.
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved SmplRate bt2 SmplRate bt1 SmplRate bt0 Reserved Reserved Reserved Reserved Resolver Dir Energize Resolution 1 Resolution 0 Reserved Cable Tune
Default xxxxxxxxxxxxxxxxxxx010xxxx0101x0
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Table 268D: FIR Filter Settings
Bit121110Taps
0001
0012
0104
0118
10016
10132
11064
111127
Table 268A: Resolution Settings
Table 268B: Resolution and Least Significant Bits Used
Table 268C: Resolution and Resolver Tracking Speed
Bit 32Resolution
0 0 10 bit resolution
0 1 12 bit resolution (default setting)
1 0 14 bit resolution
1 1 16 bit resolution
Resolution LSB Not Used Parameter 250 Increments by
16 bit All bits used 1
14 bit 2 LSB not used 4
12 bit 4 LSB not used 8
10 bit 6 LSB not used 64
Resolution
Maximum
Carrier Freq.
Tracking Speed
for X1 Resolver
Tracking Speed
for X2 Resolver
Tracking Speed
for X5 Resolver
10 bit 34 kHz 55 K-rpm 27.5 K-rpm 11 K-rpm
12 bit 24kHz 13.8 K-rpm 6.9 K-rpm 2.76 K-rpm
14 bit 14kHz 3480 rpm 1740 rpm 696 rpm
16 bit 10 kHz 900 rpm 450 rpm 180 rpm
Options
Reserved Reserved Reserved Reserved Select OK Diag Fail Power Supply Open Wire Reserved Reserved Reserved Energized -Cable Comp -Mtr Turning -Tune Result -Cable Tune
Default xxxx0000xxx00000
Bit 1514131211109876543210
0 = False
1 = True
