Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 89
Programming and Parameters Chapter 2
511 FVC2 Mode Config
Configures Field Oriented Control - 2 (FOC2) operation.
Notes: Bit changes were made for firmware version 2.003. This parameter was changed to non-linkable for firmware version 3.001.
512 PMag Mode Config
Configures Permanent Magnet (PM) operation.
• Bit 0 “PM Cogging” when set, enables torque ripple compensation.
• Bit 9 “ReflWaveComp” when set, Reflected Wave Correction is enabled.
Notes: Bit changes were made for firmware version 2.003. This parameter was changed to non-linkable for firmware version 3.001. Added bit 9 for firmware version 4.001. Bit 0 “PM Cogging” was
added for firmware version 5.002.
513 V/Hz Mode Config
Configures V/Hz control mode operation.
Notes: This parameter was added for firmware version 2.003. Changed bit 3 from “Reserved” to “FastFluxDsbl” for firmware version 3.003. Bits 8, 9, and 21 were changed to be not changeable while
the drive is running.
No. Name
Description
Values
Linkable Read-Write Data Type
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
LnfSnsr Dir LnfSnsr Use Reserved FlxRatRf Use NTC Active Reserved Reserved CEMF We Use Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved BusGain Comp Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default 00x01xx0xxxxxxxxxxxxxxx1xxxxxxxx
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
LinrSnsr Dir LinrSnsr Use Reserved FlxRatRf Use Reserved Reserved Reserved CEMF We Use Reserved Reserved Reserved Reserved PMVltRegUse PMVltRegEn Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved ReflWaveComp BusGain Comp Reserved Reserved Reserved Reserved Reserved Reserved Reserved PM Cogging
Default 00x0xxx0xxxx11xxxxxxxx11xxxxxxx0
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved VltMinorLpEn Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved ReflWaveComp BusGain Comp Reserved Reserved Reserved Reserved FastFluxDsbl Reserved Reserved Reserved
Default xxxxxxxxxx1xxxxxxxxxxx11xxxx1xxx
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
