Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

90 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
514 Test Mode Config
Configures the Motor Control (MC) test mode.
Note: This parameter was changed to non-linkable for firmware version 3.001.
515 FVC Tune Config
Configures FOC tuning mode.
• Bit 1 “FluxCurrTune” when set, the value in Par 488 [Flux Current] is used as the flux current at the beginning of the magnetic inductance test. When this bit is not set (default), an automatically
calculated (preset) flux current is used as the flux current at the beginning of the magnetic inductance test.
• Bit 2 “NoTimeLimit” when set, the time limit fault detection during the magnetizing inductance test is disabled.
Note: Bits 1 and 2 were added for firmware version 4.001.
516 FVC2 Tune Config
Configures FOC 2 tuning mode.
No. Name
Description
Values
Linkable Read-Write Data Type
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved ReflWave Comp BusGain Comp Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default xxxxxxxxxxxxxxxxxxxxxx11xxxxxxxx
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
Reserved Reserved Reserved Reserved Reserved Reserved NoRotateTune Reserved Reserved Reserved Reserved Reserved Reserved NoTimeLimit FluxCurrTune Reserved
Default xxxxxx0xxxxxx00x
Bit 1514131211109876543210
0 = False
1 = True
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
Reserved Reserved Reserved Reserved Reserved Reserved NoRotateTune Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default xxxxxx0xxxxxxxxx
Bit 1514131211109876543210
0 = False
1 = True
