Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 91
Programming and Parameters Chapter 2
517 PMag Tune Config
Configures Permanent Magnet Motor tuning mode.
518 MC Diag Status
Indicates the status of the MC diagnostic tests.
519 MC Diag Done
Indicates which MC diagnostic tests are completed.
520 PM Q Inductance
Indicates the percent-per unit inductance of the motor stator in the torque producing (q-axis).
Default:
Min/Max:
Units:
Scale:
20.00
0.00/399.99
%
100 = 8192
RW 16-bit
Integer
521 PM D Inductance
Indicates the percent-per unit inductance of the motor stator in the flux producing (d-axis).
Default:
Min/Max:
Units:
Scale:
20.00
0.00/399.99
%
100 = 8192
RW 16-bit
Integer
522 PM Stator Resist
Indicates the percent-per unit resistance of the motor stator.
Default:
Min/Max:
Units:
Scale:
1.50
0.00/100.00
%
100 = 8192
RW 16-bit
Integer
523 PM Mtr CEMF Coef
Indicates the coefficient for Counter Electro Motive Force (CEMF) voltage, normalized to base motor speed.
Default:
Min/Max:
Units:
Scale:
89.99
0.00/399.99
%
100 = 8192
RW 16-bit
Integer
525 Slip Ratio
Used by the Field Oriented Control - 2 (FOC2) mode. Indicates the present operating slip frequency at 100%
Torque Producing Current (Iqs) scaled to hertz x 100.
Default:
Min/Max:
Units:
Scale:
0.00
0.00/327.67
Hz
x 10
RO 16-bit
Integer
526 Stator Frequency
Displays stator frequency as a percentage of Par 3 [Motor NP Hertz].
Default:
Min/Max:
Units:
Scale:
0.0
-/+800.0
%
x 10
RO 16-bit
Integer
No. Name
Description
Values
Linkable Read-Write Data Type
ATTENTION: Do not modify this parameter. Motor/Drive instabilities and damage may result.
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved IndTestA set Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default xxxxxxx0xxxxxxxx
Bit 1514131211109876543210
0 = False
1 = True
A
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved PwrDiagFltPt PM EncOffset Rot Dir Chk CommCntEncls Comm Count CommParamCal CommLmEncles Comm Lm Meas Comm SigmaLs Comm Rs Meas PDgTrWP-VNOn PDgTrWP-UNOn PDgTrVP-WNOn PDgVP-UNOn PDgUP-WNOn PDgTrUP-VNOn PDgTrUNWNOn PDgTrUPWPOn Pdiag TrWNOn Pdiag TrVNOn Pdiag TrUNOn Pdiag TrWPOn Pdiag TrVPOn Pdiag TrUPOn Pdg VbusSens
Default xxxxxxx0000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
A
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved PwrDiagFltPt PM EncOffset Rot Dir Chk CommCntEncls Comm Count CommParamCal CommLmEncles Comm Lm Meas Comm SigmaLs Comm Rs Meas PDgTrWP-VNOn PDgTrWP-UNOn PDgTrVP-WNOn PDgVP-UNOn PDgUP-WNOn PDgTrUP-VNOn PDgTrUNWNOn PDgTrUPWPOn Pdiag TrWNOn Pdiag TrVNOn Pdiag TrUNOn Pdiag TrWPOn Pdiag TrVPOn Pdiag TrUPOn Pdg VbusSens
Default xxxxxxx0000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
A
A
A
A
A
