92 Rockwell Automation Publication 20D-PM001D-EN-P - March 2019
Chapter 2 Programming and Parameters
527 Start/Acc Boost
Sets the voltage boost level for starting and acceleration when “V/Hz” mode is selected.
Note: This parameter was added for firmware version 2.003.
Default:
Min/Max:
Units:
50.0
0.0/1150.0
VAC
RW 16-bit
Integer
528 Run Boost
Sets the boost level for steady state or deceleration when “V/Hz” mode is selected.
Note: This parameter was added for firmware version 2.003.
Default:
Min/Max:
Units:
50.0
0.0/1150.0
VAC
RW 16-bit
Integer
529 Break Voltage
Sets the voltage the drive will output at Par 530 [Break Frequency].
Note: This parameter was added for firmware version 2.003.
Default:
Min/Max:
Units:
1150.0
0.0/6900.0
VAC
RW 16-bit
Integer
530 Break Frequency
Sets the frequency the drive will output at Par 529 [Break Voltage].
Note: This parameter was added for firmware version 2.003.
Default:
Min/Max:
Units:
150.0
0.0/400.0
Hz
RW 16-bit
Integer
531 Maximum Voltage
Sets the highest voltage the drive will output.
Note: This parameter was added for firmware version 2.003.
Default:
Min/Max:
Units:
460.0
60.0/690.0
VAC
RW 16-bit
Integer
532 Maximum Freq
Sets the highest frequency the drive will output. This parameter is a function of Par 3 [Motor NP Hertz].
Note: This parameter was added for firmware version 2.003.
Default:
Min/Max:
Units:
(Par
3 [Motor NP Hertz] x 2) + 10Hz
Par 3 [Motor NP Hertz] + 10 Hz/420.0
Hz
RW 16-bit
Integer
533 SlewRateTimeLimt
Defines the time limit in seconds during which torque producing voltage (Vqs) regulator output variations are
limited by each slew rate at the transition where the Vqs regulator turns on. The same time limit is applied at
the transition to the slip regulator when the slip regulator turns on. A value of zero disables the slew rate
function on both the Vqs regulator output and the slip regulator output. Par 553 defines the slew rate for the
slip regulator and Par
586 [IdsCmd Slew Rate] defines the slew rate for the Vqs regulator.
Notes: This parameter was added for firmware version 3.001. This parameter was renamed from “Flux Gain
Adjust” to “SlewRateTimeLimit”, the default value was changed to “10.0” and the minimum value was
changed to “0.0” for firmware version 4.001.
Default:
Min/Max:
0.0
0.0/1126.0
RW 16-bit
Integer
534 Nth CompOff Freq
The Nth compensation current amplitude is constant (defined by Par 595 [Nth Amplitude]) up to this
frequency, then linearly reduced to zero at the frequency of Par 534 + 6.25%.
Note: This parameter was added for firmware version 5.002.
Default:
Min/Max:
Scaling:
819
0/32767
4096/Par
3 [Motor NP Hertz]
RW 16-bit
Integer
535 Mth CompOff Freq
The Mth compensation current amplitude is constant (defined by Par 598 [Mth Amplitude]) up to this
frequency, then linearly reduced to zero at the frequency of Par 535 + 6.25%.
Note: This parameter was added for firmware version 5.002.
Default:
Min/Max:
Scaling:
819
0/32767
4096/Par
3 [Motor NP Hertz]
RW 16-bit
Integer
537 SrLssAngleStblty
Adjusts the electrical angle to maintain stable motor operation. An increase in the value increases the angle
adjustment.
Default:
Min/Max:
51.0
0.0/32767.0
RW 16-bit
Integer
538 SrLss VoltStblty
Adjusts the voltage to maintain stable motor operation. An increase in the value increases the output voltage
adjustment.
Default:
Min/Max:
93.0
0.0/32767.0
RW 16-bit
Integer
539 SrLss StbltyFilt
The coefficient is used to adjust the bandwidth of a low pass filter. The smaller the value of the coefficient, the
lower the bandwidth of the filter.
Default:
Min/Max:
3250.0
0.0/32767.0
RW 16-bit
Integer
540 V/Hz Status
Indicates the limit status of the V/Hz Control Operation.
Note: This parameter was added form firmware version 2.003.
541 SrLss Angl Comp
Not currently used.
Note: This parameter was added for future use - not active for use with firmware version 2.003 and above.
Default:
Min/Max:
0.0
+/- 16384
RW 16-bit
Integer
542 SrLss Volt Comp
Not currently used.
Note: This parameter was added for future use - not active for use with firmware version 2.003 and above.
Default:
Min/Max:
Units:
100.0
+/- 1000.0
V
RW 16-bit
Integer
544 External DB Res
Sets the resistance value of an external dynamic braking resistor. This value is used to determine the power
applied to the resistor and thus calculate its temperature.
Note: This parameter was added for firmware version 4.001.
Default:
Min/Max:
Units:
49.0
0.1/500.0
Ohm
RW Real
No. Name
Description
Values
Linkable
Read-Write
Data Type
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bus Volt Lim
Current Lim
Default xxxxxxxxxxxxxx00
Bit 1514131211109876543210
0 = False
1 = True
