PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Programming and Parameters 3-57
UTILITY
User Defined
536 [UsrDefBitWrdB]
A bitmap of Pars 537 [UsrDefBitWrdB0] through 552
[UsrDefBitWrdB15]. With a parameter it is possible to read or write all
of the bits inside a word.
Example:
[UsrDefBitWrdB0] 0
[UsrDefBitWrdB1] 1 = 2
1
=2
[UsrDefBitWrdB2] 0
[UsrDefBitWrdB3] 0
[UsrDefBitWrdB4] 0
[UsrDefBitWrdB5] 1 = 2
5
= 32
[UsrDefBitWrdB6] 1 = 2
6
= 64
[UsrDefBitWrdB7] 0
[UsrDefBitWrdB8] 0
[UsrDefBitWrdB9] 0
[UsrDefBitWrdB10] 1 = 2
10
= 1024
[UsrDefBitWrdB11] 0
[UsrDefBitWrdB12] 1 = 2
12
= 4096
[UsrDefBitWrdB13] 0
[UsrDefBitWrdB14] 0
[UsrDefBitWrdB15] 0
[UsrDefBitWrdB] = 2 + 32 + 64 + 1024 + 4096 = 5218
Note: This parameter can be assigned to a digital input or output. The
bit number corresponds to the digital input/output number (e.g.,
digital input 3 uses [UsrDefBitWrdA3]). Relay Outputs 1 and 2 use
bits 14 and 15, respectively.
Default:
Min/Max:
0
0 / 65535
537 -
552
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
[UsrDefBitWrdB0]
[UsrDefBitWrdB1]
[UsrDefBitWrdB2]
[UsrDefBitWrdB3]
[UsrDefBitWrdB4]
[UsrDefBitWrdB5]
[UsrDefBitWrdB6]
[UsrDefBitWrdB7]
[UsrDefBitWrdB8]
[UsrDefBitWrdB9]
[UsrDefBitWrdB10]
[UsrDefBitWrdB11]
[UsrDefBitWrdB12]
[UsrDefBitWrdB13]
[UsrDefBitWrdB14]
[UsrDefBitWrdB15]
Bit variables. The individual “User Defined” bits can be read or written
to. It is possible to process a word with Par 536 [UsrDefBitWrdB]. See
the example in Par 536 [UsrDefBitWrdB].
Note: You can read bits 0-7 of a digital input with Par 536
[UsrDefBitWrdB] and write all of the bits associated with
[UsrDefBitWrdB] to a digital output.
Default:
Min/Max:
0
0 / 1
536
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
A
