PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Supplemental Drive Information A-17
AC Input Line Reactors and
AC Input Contactors
If a DC Contactor is used, an AC Input contactor is not needed.
Table A.M 230V AC Input, Regenerative Drives
Table A.N 230V AC Input, Non-Regenerative Drives
Drive Cat. No. DC Amps
AC Line
Amps HP
IP00 (Open Style) Line Reactor
Cat No. Line Reactor kW (HP) AC Input Contactor Cat. No.
20P-41AB7P0 7 5.7 1.5 1321-3R8-A .75 (1) 100-C12D10
20P-41AB9P0 9 7.4 2 1321-3R12-A 1.49 (2) 100-C12D10
20P-41AB012 12 9.8 3 1321-3R18-A 0.75-3.7 (1-5) 100-C12D10
20P-41AB020 20 16 5 1321-3R18-A 0.75-3.7 (1-5) 100-C23D10
20P-41AB029 29 24 7.5 1321-3R55-A 5.5-11 (7.5-15) 100-C30D10
20P-41AB038 38 31 10 1321-3R55-A 5.5-11 (7.5-15) 100-C37D10
20P-41AB055 55 45 15 1321-3R55-A 5.5-11 (7.5-15) 100-C60D10
20P-41AB073 73 60 20 1321-3R80-A 15 (20) 100-C60D10
20P-41AB093 93 76 25 1321-3R100-A 18.5-22 (25-30) 100-C85D10
20P-41AB110 110 90 30 1321-3R100-A 18.5-22 (25-30) 100-D110D11
20P-41AB146 146 119 40 1321-3R160-A 30-37 (40-50) 100-D140D11
20P-41AB180 180 147 50 1321-3R160-A 30-37 (40-50) 100-D180D11
20P-41AB218 218 178 60 1321-3RB250-A 45-56 (60-75) 100-D180D11
20P-41AB265 265 217 75 1321-3RB250-A 45-56 (60-75) 100-D250ED11
20P-41AB360 360 294 100 1321-3RB320-A 75 (100) 100-D300ED11
20P-41AB434 434 355 125 1321-3RB400-A 93 (125) 100-D420ED11
20P-41AB521 521 426 150 1321-3R500-A 112 (150) 100-D630ED11
Drive Cat. No. DC Amps
AC Line
Amps HP
IP00 (Open Style)
Line Reactor Cat No. Line Reactor kW (HP) AC Input Contactor Cat. No.
20P-21AB7P0 7 5.7 1.5 1321-3R8-A .75 (1) 100-C12D10
20P-21AB9P0 9 7.4 2 1321-3R12-A 1.49 (2) 100-C12D10
20P-21AB012 12 9.8 3 1321-3R18-A 0.75-3.7 (1-5) 100-C12D10
20P-21AB020 20 16 5 1321-3R18-A 0.75-3.7 (1-5) 100-C23D10
20P-21AB029 29 24 7.5 1321-3R55-A 5.5-11 (7.5-15) 100-C30D10
20P-21AB038 38 31 10 1321-3R55-A 5.5-11 (7.5-15) 100-C37D10
20P-21AB055 55 45 15 1321-3R55-A 5.5-11 (7.5-15) 100-C60D10
20P-21AB073 73 60 20 1321-3R80-A 15 (20) 100-C60D10
20P-21AB093 93 76 25 1321-3R100-A 18.5-22 (25-30) 100-C85D10
20P-21AB110 110 90 30 1321-3R100-A 18.5-22 (25-30) 100-D110D11
20P-21AB146 146 119 40 1321-3R160-A 30-37 (40-50) 100-D140D11
20P-21AB180 180 147 50 1321-3R160-A 30-37 (40-50) 100-D180D11
20P-21AB218 218 178 60 1321-3RB250-A 45-56 (60-75) 100-D180D11
20P-21AB265 265 217 75 1321-3RB250-A 45-56 (60-75) 100-D250ED11
20P-21AB360 360 294 100 1321-3RB320-A 75 (100) 100-D300ED11
20P-21AB434 434 355 125 1321-3RB400-A 93 (125) 100-D420ED11
20P-21AB521 521 426 150 1321-3R500-A 112 (150) 100-D630ED11
