PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
A-18 Supplemental Drive Information
Table A.O 460V AC Input, Regenerative Drives
Table A.P 460V AC Input, Non-Regenerative Drives
Drive Cat. No. DC Amps
AC Line
Amps HP
IP00 (Open Style)
Line Reactor Cat No. Line Reactor kW (HP) AC Input Contactor Cat. No.
20P-41AD4P1 4.1 3.3 2 1321-3R4-A .55 (.75) 100-C12D10
20P-41AD6P0 6 4.9 3 1321-3R8-A .75 (1) 100-C12D10
20P-41AD010 10 8.2 5 1321-3R18-B 1.5-7.5 (2-10) 100-C12D10
20P-41AD014 14 11.4 7.5 1321-3R18-B 1.5-7.5 (2-10) 100-C12D10
20P-41AD019 19 15.5 10 1321-3R18-B 1.5-7.5 (2-10) 100-C23D10
20P-41AD027 27 22.1 15 1321-3R55-B 11-22 (15-30) 100-C23D10
20P-41AD035 35 28.6 20 1321-3R55-B 11-22 (15-30) 100-C30D10
20P-41AD045 45 36.8 25 1321-3R55-B 11-22 (15-30) 100-C37D10
20P-41AD052 52 42.5 30 1321-3R55-B 11-22 (15-30) 100-C43D10
20P-41AD073 73 59.6 40 1321-3R80-B 30 (40) 100-C60D10
20P-41AD086 86 70.3 50 1321-3R100-B 37-45 (50-60) 100-C85D10
20P-41AD100 100 81.7 60 1321-3R100-B 37-45 (50-60) 100-C85D10
20P-41AD129 129 105.4 75 1321-3R160-B 56-75 (75-100) 100-D110D11
20P-41AD167 167 136.4 100 1321-3R160-B 56-75 (75-100) 100-D140D11
20P-41AD207 207 169.1 125 1321-3RB250-B 93-112 (125-150) 100-D180D11
20P-41AD250 250 204.3 150 1321-3RB250-B 93-112 (125-150) 100-D210ED11
20P-41AD330 330 269.6 200 1321-3RB320-B 149 (200) 100-D300ED11
20P-41AD412 412 336.6 250 1321-3RB400-B 186.4 (250) 100-D420ED11
20P-41AD495 495 404.4 300 1321-3R500-B 223.7 (300) 100-D420ED11
20P-41AD667 667 544.9 400 1321-3R600-B 298.3 (400) 100-D630ED11
Drive Cat. No. DC Amps
AC Line
Amps HP
IP00 (Open Style)
Line Reactor Cat No. Line Reactor kW (HP) AC Input Contactor Cat. No.
20P-21AD4P1 4.1 3.3 2 1321-3R4-A .55 (.75) 100-C12D10
20P-21AD6P0 6 4.9 3 1321-3R8-A .75 (1) 100-C12D10
20P-21AD010 10 8.2 5 1321-3R18-B 1.5-7.5 (2-10) 100-C12D10
20P-21AD014 14 11.4 7.5 1321-3R18-B 1.5-7.5 (2-10) 100-C12D10
20P-21AD019 19 15.5 10 1321-3R18-B 1.5-7.5 (2-10) 100-C23D10
20P-21AD027 27 22.1 15 1321-3R55-B 11-22 (15-30) 100-C23D10
20P-21AD035 35 28.6 20 1321-3R55-B 11-22 (15-30) 100-C30D10
20P-21AD045 45 36.8 25 1321-3R55-B 11-22 (15-30) 100-C37D10
20P-21AD052 52 42.5 30 1321-3R55-B 11-22 (15-30) 100-C43D10
20P-21AD073 73 59.6 40 1321-3R80-B 30 (40) 100-C60D10
20P-21AD086 86 70.3 50 1321-3R100-B 37-45 (50-60) 100-C85D10
20P-21AD100 100 81.7 60 1321-3R100-B 37-45 (50-60) 100-C85D10
20P-21AD129 129 105.4 75 1321-3R160-B 56-75 (75-100) 100-D110D11
20P-21AD167 167 136.4 100 1321-3R160-B 56-75 (75-100) 100-D140D11
20P-21AD207 207 169.1 125 1321-3RB250-B 93-112 (125-150) 100-D180D11
20P-21AD250 250 204.3 150 1321-3RB250-B 93-112 (125-150) 100-D210ED11
20P-21AD330 330 269.6 200 1321-3RB320-B 149 (200) 100-D300ED11
20P-21AD412 412 336.6 250 1321-3RB400-B 186.4 (250) 100-D420ED11
20P-21AD495 495 404.4 300 1321-3R500-B 223.7 (300) 100-D420ED11
20P-21AD667 667 544.9 400 1321-3R600-B 298.3 (400) 100-D630ED11
