PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Supplemental Drive Information A-19
DC Output Contactors and
Dynamic Brake Resistor
Kits
Table A.Q 230V AC Input, Regenerative Drives
Table A.R 230V AC Input, Non-Regenerative Drives
Drive Cat. No.
DC
Amps
AC Line
Amps HP
Dynamic
Brake
Resistor Kit
Cat. No.
Armature
Voltage
(Volts)
DB
Resistor
Size (ohms)
DB
Resistor
Size
(Watts)
Brake
Amps
Required
DC Loop
Contactor Cat.
No.
(3)
DC Contactor
Crimp Lugs Cat.
No.
(6)
20P-41AB7P0 7 5.7 1.5 1370-DBL62 240 20 420 12.00 1370-DC56 1370-LG40
20P-41AB9P0 9 7.4 2 1370-DBL63 240 20 420 12.00 1370-DC56 1370-LG40
20P-41AB012 12 9.8 3 1370-DBL64 240 15 420 16.00 1370-DC56 1370-LG40
20P-41AB020 20 16 5 1370-DBL65 240 8.6 420 27.91 1370-DC56 1370-LG40
20P-41AB029 29 24 7.5 1370-DBL66 240 6 345 40.00 1370-DC56 1370-LG40
20P-41AB038 38 31 10 1370-DBL67 240 5 330 48.00 1370-DC56 1370-LG40
20P-41AB055 55 45 15 1370-DBL68 240 3.5 385 68.57 1370-DC56 1370-LG56
20P-41AB073 73 60 20 1370-DBL69 240 2.6 385 92.31 1370-DC110 1370-LG92
20P-41AB093 93 76 25 1370-DBL70 240 2 330 120.00 1370-DC110 1370-LG92
20P-41AB110 110 90 30 1370-DBL71 240 2 330 120.00 1370-DC110 1370-LG110
20P-41AB146 146 119 40 1370-DBL72 240 0.7 280 342.86 1370-DC180 1370-LG160
20P-41AB180 180 147 50 1370-DBL73 240 0.5 365 480.00 1370-DC180 1370-LG180
20P-41AB218 218 178 60 1370-DBL74 240 0.5 365 480.00 1370-DC280 1370-LG228
20P-41AB265 265 217 75 1370-DBL75 240 2 330 120.00 1370-DC280 1370-LG268
20P-41AB360 360 294 100 1370-DBL76 240 1.4 290 171.43
(4) (7)
20P-41AB434 434 355 125
(1)
240 0.5 1458 651
(5) (7)
20P-41AB521 521 426 150
(2)
240 0.322 6221 781
(5) (7)
(1)
Qty 4-CUTLER-HAMMER_G3AP50 Two in series, two in parallel. Must be sourced separately from drive.
(2)
HUBBELL_Y139W322GB - Must be sourced separately from drive.
(3)
Coil voltage = 115V AC, 50/60Hz.
(4)
ABB_EHDB360C-1L-22 - ABB Contactor for drives with a dynamic brake. Must be sourcing separately from drive.
(5)
ABB_EHDB520C2P-1L - ABB Contactor for drives with no Dynamic Brake. ABB_EHDB520C-1L - ABB Contactor for drives with Dynamic Brake. Must be sourced separately from drive.
(6)
See DC Contactor Crimp Lug Kit Specifications on page A-21 for more information.
(7)
Wire and Lug size dependant on Cabinet dims and local codes.
Drive Cat.
No.
DC
Amps
AC
Line
Amps HP
Dynamic
Brake
Resistor Kit
Cat. No.
Armature
Voltage
(Volts)
DB
Resistor
Size
(ohms)
DB
Resistor
Size
(Watts)
Brake
Amps
Required
DC Loop
Contactor Cat.
No.
(3)
DC Contactor
Crimp Lugs Cat.
No.
(6)
20P-21AB7P0 7 5.7 1.5 1370-DBL62 240 20 420 12.00 1370-DC56 1370-LG40
20P-21AB9P0 9 7.4 2 1370-DBL63 240 20 420 12.00 1370-DC56 1370-LG40
20P-21AB012 12 9.8 3 1370-DBL64 240 15 420 16.00 1370-DC56 1370-LG40
20P-21AB020 20 16 5 1370-DBL65 240 8.6 420 27.91 1370-DC56 1370-LG40
20P-21AB029 29 24 7.5 1370-DBL66 240 6 345 40.00 1370-DC56 1370-LG40
20P-21AB038 38 31 10 1370-DBL67 240 5 330 48.00 1370-DC56 1370-LG40
20P-21AB055 55 45 15 1370-DBL68 240 3.5 385 68.57 1370-DC56 1370-LG56
20P-21AB073 73 60 20 1370-DBL69 240 2.6 385 92.31 1370-DC110 1370-LG92
20P-21AB093 93 76 25 1370-DBL70 240 2 330 120.00 1370-DC110 1370-LG92
20P-21AB110 110 90 30 1370-DBL71 240 2 330 120.00 1370-DC110 1370-LG110
20P-21AB146 146 119 40 1370-DBL72 240 0.7 280 342.86 1370-DC180 1370-LG160
20P-21AB180 180 147 50 1370-DBL73 240 0.5 365 480.00 1370-DC180 1370-LG180
20P-21AB218 218 178 60 1370-DBL74 240 0.5 365 480.00 1370-DC280 1370-LG228
20P-21AB265 265 217 75 1370-DBL75 240 2 330 120.00 1370-DC280 1370-LG268
20P-21AB360 360 294 100 1370-DBL76 240 1.4 290 171.43
(4) (7)
20P-21AB434 434 355 125
(1)
240 0.5 1458 –
(5) (7)
20P-21AB521 521 426 150
(2)
240 0.322 6221 –
(5) (7)
(1)
Qty 4-CUTLER-HAMMER_G3AP50 Two in series, two in parallel. Must be sourced separately from drive.
(2)
HUBBELL_Y139W322GB - Must be sourced separately from drive.
(3)
Coil voltage = 115V AC, 50/60Hz.
(4)
ABB_EHDB360C-1L-22 - ABB Contactor for drives with a dynamic brake. Must be sourcing separately from drive.
(5)
ABB_EHDB520C2P-1L - ABB Contactor for drives with no Dynamic Brake. ABB_EHDB520C-1L - ABB Contactor for drives with Dynamic Brake. Must be sourced separately from drive.
(6)
See DC Contactor Crimp Lug Kit Specifications on page A-21 for more information.
(7)
Wire and Lug size dependant on Cabinet dims and local codes.
