PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008

A-20 Supplemental Drive Information

Table A.S 460V AC Input, Regenerative Drives

Drive Cat.

No.

Amps

Line

Amps HP

Dynamic

Brake

Resistor Kit

Cat. No.

Armature

Voltage

(Volts)

Resistor

Size (ohms)

DB Resistor

Size (Watts)

Brake

Amps

Required

DC Loop

Contactor Cat.

No.

(4)

DC Contactor

Crimp Lugs Cat.

No.

(9)

20P-41AD4P1 4.1 3.3 2 1370-DBH63 500 81 255 6.17 1370-DC56 1370-LG40

20P-41AD6P0 6 4.9 3 1370-DBH64 500 62 245 8.06 1370-DC56 1370-LG40

20P-41AD010 10 8.2 5 1370-DBH65 500 45 245 11.11 1370-DC56 1370-LG40

20P-41AD014 14 11.4 7.5 1370-DBH66 500 27 350 18.52 1370-DC56 1370-LG40

20P-41AD019 19 15.5 10 1370-DBH67 500 20 420 25.00 1370-DC56 1370-LG40

20P-41AD027 27 22.1 15 1370-DBH68 500 12 405 41.67 1370-DC56 1370-LG40

20P-41AD035 35 28.6 20 1370-DBH69 500 5 330 100.00 1370-DC56 1370-LG40

20P-41AD045 45 36.8 25 1370-DBH70 500 4.5 330 111.11 1370-DC56 1370-LG52

20P-41AD052 52 42.5 30 1370-DBH71 500 3.5 385 142.86 1370-DC56 1370-LG52

20P-41AD073 73 59.6 40 1370-DBH72 500 2.6 345 192.31 1370-DC110 1370-LG92

20P-41AD086 86 70.3 50 1370-DBH73 500 2 345 250.00 1370-DC110 1370-LG92

20P-41AD100 100 81.7 60 1370-DBH74 500 2 345 250.00 1370-DC110 1370-LG110

20P-41AD129 129 105.4 75 1370-DBH75 500 1 270 500.00 1370-DC180 1370-LG140

20P-41AD167 167 136.4 100 1370-DBH76 500 0.7 280 714.29 1370-DC180 1370-LG180

20P-41AD207 207 169.1 125 1370-DBH77 500 0.7 280 714.29 1370-DC280 1370-LG228

20P-41AD250 250 204.3 150 1370-DBH78 500 0.5 365 1000.00 1370-DC280 1370-LG268

20P-41AD330 330 269.6 200 1370-DBH79 500 0.7 280 714.29

(5) (10)

20P-41AD412 412 336.6 250

(1)

500 0.808 7292 –

(6) (10)

20P-41AD495 495 404.4 300

(2)

500 0.595 6069 –

(7) (10)

20P-41AD667 667 544.9 400

(3)

500 0.542 6439 –

(8) (10)

(1)

HUBBELL_Y95W808GB - Must be sourced separately from drive.

(2)

HUBBELL_Y101W595GB - Must be sourced separately from drive.

(3)

HUBBELL_Y109W542GB - Must be sourced separately from drive.

(4)

Coil voltage = 115V AC, 50/60Hz.

(5)

ABB_EHDB360C-1L-22 - ABB Contactor for drives with a dynamic brake. Must be sourcing separately from drive.

(6)

ABB_EHDB520C2P-1L - ABB contactor for drives with no dynamic brake. ABB_EHDB520C-1L - ABB contactor for drives with a dynamic brake. Must be sourced separately from drive.

(7)

ABB_EHDB650C2P-1L - ABB contactor for drives with no dynamic brake. ABB_EHDB650C-1L - ABB contactor for drives with a dynamic brake. Must be sourced separately from drive.

(8)

ABB_EHDB800C2P-1L - ABB contactor for drives with no dynamic brake. ABB_EHDB800C-1L - ABB contactor for drives with a dynamic brake. Must be sourced separately from drive.

(9)

See DC Contactor Crimp Lug Kit Specifications on page A-21 for more information.

(10)

Wire and Lug size dependant on Cabinet dims and local codes.
