MODIFICATIONS
!
Warning: do not modify or replace parts of the product without
wrien and signed authorizaon by the manufacturer. Modicaons or
replacements that are not authorized in wring may cause damage to
people, animals and property. Each modicaon or replacement of parts
made and not authorized in wring by the manufacturer is prohibited and
release the manufacturer from any direct and indirect liability arising from
damages to persons and property.
4 DESCRIPTION OF THE PRODUCT
The Agilik series automac road barrier is available in 4 standard models,
described below; also, it is possible to customize installaon with the various
standard accessories described in detail in this installaon manual.
4.1) Models and characteriscs:
AG/004
Agilik brushless 36V DC Barrier for bars up to 4
metres, with on-board control unit, absolute encoder,
complete with fixing base with tie rods and screws,
and bar fixing flange.
AG/004/115V
Agilik brushless 36V DC Barrier for bars up to 4
metres, with on-board control unit, absolute encoder,
complete with fixing base with tie rods and screws,
and bar fixing flange. For line voltages of 115V.
AG/004/IS
Agilik brushless 36V DC Barrier for bars up to 4
metres, with on-board control unit, absolute encoder,
complete with fixing base with tie rods and screws,
and bar fixing flange. Frame made in Brushed stainless
steel AISI 304
AG/006
Agilik brushless 36V DC Barrier for bars up to 6
metres, with on-board control unit, absolute encoder,
complete with fixing base with tie rods and screws,
and bar fixing flange.
AG/006/115V
Agilik brushless 36V DC Barrier for bars up to 6
metres, with on-board control unit, absolute encoder,
complete with fixing base with tie rods and screws,
and bar fixing flange. For line voltages of 115V.
AS/006/IS
Agilik brushless 36V DC Barrier for bars up to 6
metres, with on-board control unit, absolute encoder,
complete with fixing base with tie rods and screws,
and bar fixing flange. Frame made in Brushed stainless
steel AISI 304
4.2) Accessories list:
See Fig. 1
1) Carbon steel barrier assembly cabinet with an-corrosion treatment,
painted.
2) Aluminium bar support base, die-cast, painted.
3) Extruded aluminium bar, painted white.
4) Galvanized steel omega support for securing the bar.
5) Aluminium bar xing cover, die-cast, painted.
6) Aluminium head, die-cast, painted.
7) Semi-transparent ashing cover.
8) Digital control unit.
9) Mechanical stop in opening and closing
10) Galvanized steel spring xing arm.
11) Geared motor complete with brushless motor and absolute encoder.
12) Key release with DIN cylinder.
13) Corrosion-resistant steel closing door, painted.
14) AG/BA2/01 ellipcal bar up to 2 metres made of aluminium, painted
white, with slot cover proles and shockproof rubber.
15) AG/BA3/01 ellipcal bar up to 3 metres made of aluminium, painted
white, with slot cover proles and shockproof rubber.
16) AG/BA4/01 ellipcal bar up to 4 metres made of aluminium, painted
white, with slot cover proles and shockproof rubber.
17) AG/BA6/01 ellipcal bar up to 6 metres made of aluminium, painted
white, with slot cover proles and shockproof rubber.
18) KT230 Galvanised foundaon plate for securing the barrier.
19) AG/SP72/01 Ø 72 spring for bars of up to 4 metres.
20) AG/SP83/01 Ø 83 spring for bars of up to 6 metres.
21) AG/BLED Flashing LED 4-board circuit.
22) AG/ALED6C - AG/ALED/8C - AG/ALED/12C Strip LED 6 - 8 - 12 metres with
connecons cable.
23) AG/BAMS/01 Mobile support for bars.
24) KT231 Fixed support foundaon plate.
25) AG/BAFS/01 Fixed support with rubber, non-adjustable.
26) AG/BAFS/03 Fixed support with rubber, non-adjustable, with provision
of a bolt.
27) AG/BAFS/02 Fixed support with rubber, adjustable, telescopic.
28) AG/BAFS/04 Fixed support with rubber, adjustable, telescopic, with
provision of a bolt.
29) AG/BAJ/01 Internal connecon joint made of anodized aluminium.
30) Emergency baeries module (oponal).
31) Pack of No. 40 reecve adhesive strips for the bar.
5 TECHNICAL CHARACTERISTICS
AG SERIES AG/004 AG/004/115V AG/006 AG/006/115V
BARRIER UP TO 4 METRES UP TO 4 METRES UP TO 6 METRES UP TO 6 METRES
FREQUENCY OF USE SUPER INTENSIVE SUPER INTENSIVE SUPER INTENSIVE SUPER INTENSIVE
TRAVEL CONTROL SYSTEM
ABSOLUTE ENCODER
DIGITAL
ABSOLUTE ENCODER
DIGITAL
ABSOLUTE ENCODER
DIGITAL
ABSOLUTE ENCODER
DIGITAL
POWER SUPPLY
230 V AC - 50 Hz ±10% 115 V AC 60 HZ ±10% 230 V AC - 50 Hz ±10% 115 V AC 60 HZ ±10%
MOTOR POWER SUPPLY FROM 0 TO 36 V DC FROM 0 TO 36 V DC FROM 0 TO 36 V DC FROM 0 TO 36 V DC
POWER CONSUMPTION FROM 0 TO 15 A FROM 0 TO 15 A FROM 0 TO 15 A FROM 0 TO 15 A
POWER MOTOR 200 W 200 W 200 W 200 W
TORQUE FROM 0 TO 200 Nm FROM 0 TO 200 Nm FROM 0 TO 200 Nm FROM 0 TO 200 Nm
OPEN / CLOSE TIME 90 ° FROM 2 TO 6 seconds FROM 2 TO 6 seconds FROM 4 TO 8 seconds FROM 4 TO 8 seconds
OPERATING TEMPERATURE -20 +55 °C -20 +55 °C -20 +55 °C -20 +55 °C
ACCESSORIES POWER SUPPLY 24 V DC 24 V DC 24 V DC 24 V DC
CONTROL UNIT (INTEGRATED)
DIGITAL CONTROLLER
36V DC
DIGITAL CONTROLLER
36V DC
DIGITAL CONTROLLER
36V DC
DIGITAL CONTROLLER
36V DC
RELEASE SYSTEM KEY WITH DIN CYLINDER KEY WITH DIN CYLINDER KEY WITH DIN CYLINDER KEY WITH DIN CYLINDER
PROTECTION RATING IP 54 IP 54 IP 54 IP 54
EMERGENCY BATTERY AVAILABLE (OPTIONAL) AVAILABLE (OPTIONAL) AVAILABLE (OPTIONAL) AVAILABLE (OPTIONAL)
OPERATING CYCLES PER DAY (OPENING/
CLOSING - 24 HOURS NO STOP)
n° 5000 n° 5000 n° 4000 n° 4000
