Roger Technology AGILIK Series User Manual

26
CONNECTION CABLE TYPE
CABLE LENGTH
1 - 10 m
CABLE LENGTH
10 - 20 m
CABLE LENGTH
20 - 30 m
230V Power supply
OUTDOOR CABLES FOR
UNDERGROUND INSTALLATION
CEI EN 50267-2-1
3 x 2.5 mm² 3 x 2.5 mm² 3 x 4 mm²
Photocell transmiers 2 x 0.5 mm² 2 x 0.5 mm² 2 x 0.5 mm²
Photocell receivers 4 x 0.5 mm² 4 x 0.5 mm² 4 x 0.5 mm²
24V accessory power 2 x 0.5 mm² 2 x 0.5 mm² 2 x 1 mm²
Safety and control devices 2 x 0.5 mm² 2 x 0.5 mm² 2 x 0.5 mm²
Antenna Connecon RG58 MAX 10 m
1
2345
67
8910411
The automaon is designed to be powered by the mains supply at 230V AC
50 Hz.
Therefore, connect the automaon to the mains through a double insulated
3x2.5 mm² cable, making it pass through a submerged pipe prepared during
the installaon of the KT230 foundaon plate (see Fig.3).
Once inside the cabinet, the cable must connue upward on the le side of
the automaon; insert it through the rubber cable gland to the le of the
box and connect it to the terminal block with a fuse, as shown in Fig. 22.
Ensure the cable so that it does not suer damage during the movement of
the mechanical parts inside the cabinet.
15.1) Type of connecon cables and minimum thicknesses
16 INSTALLATION OF A SYSTEM TYPE
15 ELECTRICAL CONNECTIONS
Here we list the components needed for installaon of a system type of an Agilik 4 or Agilik 6 series automaon.
N
L
22
1) Automac Barrier Agilik 4 or Agilik 6 Series.
2) integrated control unit.
3) Flashing lights.
4) External Photocell
5) Bar with shockproof rubber and LED strip.
6) Reecve scker.
9) Internal Photocell
10) Fixed support for bar.
11) Key or keypad release switch
