Roland GR-540 User Manual

Step 6: Set the Alignment Method
(Sensor Mode)
Position the crop marks automatically using the machine's integrated sensor.
Procedure
Press [MENU] several times to display the screen shown in the figure.
Press [ ] several times to display the screen shown in the figure.
Press [ ] once, and then press [ ] several times to select [SENSOR
MODE]
Press [ENTER] to select the setting.
Press [MENU] to return to the screen shown in the figure.

Roland GR-540 Specifications

General

Max Media Width	610 mm
Supported OS	Windows, Mac
Power Supply	AC 100-240V, 50/60Hz
Blade Holder	Standard
Interface	USB
Cutting Width	540 mm
