Roland RD-300NX User Manual

14
Getting Ready
Connecting the AC Adaptor
1. Make sure that the [POWER] switch is o.
2. Move the [VOLUME] slider all the way down to minimize the volume.
3. Connect the supplied Power Cord to the included AC adaptor.
Power Cord
AC Outlet
Indicator
AC Adaptor
Place the AC adaptor so the side with the indicator (see illustration) faces upwards and the side with textual information faces downwards.
The indicator will light when you plug the AC adaptor into an AC outlet.
4. Connect the included AC adaptor to the DC IN jack located on the RD-300NX’s rear panel, and plug the power cord into an AC
outlet.
932

Roland RD-300NX Specifications

General

Max Polyphony	128 voices
Metronome	Yes
Keyboard	88 keys
Sound Generator	SuperNATURAL Piano
Effects	Reverb, Chorus, 3-band EQ
Display	128 x 64 dots graphic LCD
Power Supply	AC Adaptor
Connectors	Output jacks (L/MONO, R), Input jacks (L/MONO, R), MIDI connectors (IN, OUT), USB COMPUTER port, USB MEMORY port
Included Accessories	Owner's Manual, AC Adaptor, Power Cord, Damper Pedal
