132
Using insertion effects
■ Using Control Change 16 to modify the Wah Man value of 50:GTR Multi3
< Settings >
1 Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2 Set the effect type to 50: GTR Multi 3 (value: 04H 02H)
F0 41 10 42 12 40 03 00 04 02 37 F7
3 Set Wah Man (address: 40H 03H 04H) to 0 (00H).
F0 41 10 42 12 40 03 04 00 39 F7
4 Set Effect Control Source 1 (address: 40H 03H 1BH) to CC16 (10H).
F0 41 10 42 12 40 03 1B 10 12 F7
5 Set Effect Control Depth 1 (address: 40H 03H 1CH) to +100% (7FH).
F0 41 10 42 12 40 03 1C 7F 22 F7
< Modifying the value >
CC#16 0 Wah Man → 0
1 Wah Man → 1
::
126 Wah Man → 126
127 Wah Man → 127
■ Using Control Change 17 to modify the Feedback value of 10: Stereo Flanger
Example 1:When Effect Control Depth is set to +100
< Settings >
1 Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2 Set the effect type to 10: Stereo Flanger (value: 01H 23H)
F0 41 10 42 12 40 03 00 01 23 19 F7
3 Set Feedback (address: 40H 03H 08H) to -98% (00H).
F0 41 10 42 12 40 03 08 00 35 F7
4 Set Effect Control Source 2 (address: 40H 03H 1DH) to CC17 (11H).
F0 41 10 42 12 40 03 1D 11 0F F7
5 Set Effect Control Depth 2 (address: 40H 03H 1EH) to +100% (7FH).
F0 41 10 42 12 40 03 1E 7F 20 F7
< Modifying the value >
The Feedback parameter changes in 2% steps, with 64 as the center.
CC#17 0 Feedback → -98%
::
15 Feedback → -98%
16 Feedback → -96%
::
62 Feedback → -4%
63 Feedback → -2%
64 Feedback → +/-0%
65 Feedback → +2%
66 Feedback → +4%
::
112 Feedback → +96%
113 Feedback → +98%
::
127 Feedback → +98%
For details about the
hexadecimal values and
their corresponding
parameter value, refer to
Effect Parameter Value
Conversion Table (p.224).
