218
Appendices
❍ Effects that reverberate the sound
(delay/reverb type)
Parameter Setting Value Value (Hex.) MSB/LSB (H)
21 : Stereo Delay 01 50
Dly Tm L 0–150ms–500ms *4 03
Dly Tm R 0–300ms–500ms *4 04
+ Feedback -98%–+48%–+98% 0F–71 05
Fb Mode Norm/Cross 00/01 06
Phase L Norm/Invert 00/01 07
Phase R Norm/Invert 00/01 08
HF Damp 315–8k/Bypass *8 0A
# Balance D> 0E–D>74E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
22 : Mod Delay 01 51
Dly Tm L 0–40ms–500ms *4 03
Dly Tm R 0–220ms–500ms *4 04
Feedback -98%–+48%–+98% 0F–71 05
Fb Mode Norm/Cross 00/01 06
+ Mod Rate 0.05–0.65–10.0 *6 07
Mod Depth 0–21–127 00–7F 08
Mod Phase 0–180 00–5A 09
HF Damp 315–8k/Bypass *8 0A
# Balance D> 0E–D>61E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
23 : 3 Tap Delay 01 52
Dly Tm C 200ms–300ms–990ms/1sec *2 03
Dly Tm L 200ms–200ms–990ms/1sec *2 04
Dly Tm R 200ms–235ms–990ms/1sec *2 05
+ Feedback -98%–+32%–+98% 0F–71 06
Dly Lev C 0–127 00–7F 07
Dly Lev L 0–127 00–7F 08
Dly Lev R 0–127 00–7F 09
HF Damp 315–8k/Bypass *8 0A
# Balance D> 0E–D>74E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
24 : 4 Tap Delay 01 53
Dly Tm 1 200ms–500ms–990ms/1sec *2 03
Dly Tm 2 200ms–300ms–990ms/1sec *2 04
Dly Tm 3 200ms–400ms–990ms/1sec *2 05
Dly Tm 4 200ms–200ms–990ms/1sec *2 06
Dly Lev 1 0–127 00–7F 07
Dly Lev 2 0–127 00–7F 08
Dly Lev 3 0–127 00–7F 09
Dly Lev 4 0–127 00–7F 0A
+ Feedback -98%–+32%–+98% 0F–71 0B
HF Damp 315–8k/Bypass *8 0C
# Balance D> 0E–D>74E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
25 : Tm Ctrl Delay 01 54
+ Dly Time 200ms–500ms–990ms/1sec *3 03
Accel 0–10–15 *14 04
# Feedback -98%–+32%–+98% 0F–71 05
HF Damp 315–8k/Bypass *8 06
EFX Pan L63–0–R63 00–7F 07
Balance D> 0E–D>74E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
Parameter Setting Value Value (Hex.) MSB/LSB (H)
26 : Reverb 01 55
Type Room1/2/Stage1/2/Hall1/200/01/02/03/04/05 03
Pre Dly 0–74ms–100ms *1 04
+ Time 0–120–127 00–7F 05
HF Damp 315–6.3k–8k/Bypass *8 06
# Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
27 : Gate Reverb 01 56
Type Norm/Reverse/Sweep1/2 00/01/02/03 03
Pre Dly 0–0.5ms–100ms *1 04
Gate Time 0–65ms–500ms 00–63 05
+ Balance D> 0E–D>65E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–-3–+12 34–4C 14
# Level 0–112–127 00–7F 16
28 : 3D Delay 01 57
Dly Tm C 0–300ms–500ms *4 03
Dly Tm L 0–200ms–500ms *4 04
Dly Tm R 0–240ms–500ms *4 05
+ Feedback -98%–+32%–+98% 0F–71 06
Dly Lev C 0–40–127 00–7F 07
Dly Lev L 0–64–127 00–7F 08
Dly Lev R 0–64–127 00–7F 09
HF Damp 315–8k/Bypass *8 0A
Out Speaker/Phones 00/01 11
# Balance D> 0E–D>74E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
❍
Effects that modify the pitch (pitch/shift type)
29 : 2 Pitch Shifter 01 60
+ Coarse 1 -24–+7–+12 28–4C 03
Fine 1 -100–-4–+100 0E–72 04
Pre Dly 1 0–100ms *1 05
EFX Pan 1 L63–0–R63 00–7F 06
# Coarse 2 -24–-5–+12 28–4C 07
Fine 2 -100–+4–+100 0E–72 08
Pre Dly 2 0–100ms *1 09
EFX Pan 2 L63–0–R63 00–7F 0A
Shift Mode 1–3–500–04 0B
L.Bal A> 0B–A=B–A 0<B 00–7F 0C
Balance D> 0E–D>74E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–95–127 00–7F 16
30 : Fb P.Shifter 01 61
+ P.Coarse -24–+7–+12 28–4C 03
P.Fine -100–0–+100 0E–72 04
# Feedback -98%–+40%–+98% 0F–71 05
Pre Dly 0–45ms–100ms *1 06
Mode 1–3–500–04 07
EFX Pan L63–0–R63 00–7F 08
Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–-6–+12 34–4C 14
Level 0–127 00–7F 16
