Roland Sound Canvas SC-8850 User Manual

219
Appendices
❍ Others
Parameter Setting Value Value (Hex.) MSB/LSB (H)
31 : 3D Auto 01 70
Azimuth 180/L168–0–R168 *13 03
+ Speed 0.05–1.30–10.0 *6 04
Clockwise -/+ 00/01 05
# Turn Off/On 00/01 06
Out Speaker/Phones 00/01 11
Level 0–127 00–7F 16
32 : 3D Manual 01 71
+ Azimuth 180/L168–0–R168 *13 03
Out Speaker/Phones 00/01 11
# Level 0–127 00–7F 16
33 : Lo-Fi 1 01 72
Pre Filter 1–2–600–05 03
Lo-Fi Type 1–6–900–08 04
Post Filter 1–2–600–05 05
+ Balance D> 0E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
# Pan L63–0–R63 00–7F 15
Level 0–127 00–7F 16
34 : Lo-Fi 2 01 73
Lo-Fi Type 1–2–600–05 03
Fil Type Off/LPF/HPF 00/01/02 04
Cutoff 250–630–8k *9 05
+ R.Detune 0–127 00–7F 06
R.Nz Lev 0–64–127 00–7F 07
W/P Sel White/Pink 00/01 08
W/P LPF 250–6.3k/Bypass *11 09
W/P Level 0–127 00–7F 0A
Disc Type LP/EP/SP/RND 00/01/02/03 0B
Disc LPF 250–6.3k/Bypass *11 0C
Disc Nz Lev 0–127 00–7F 0D
Hum Type 50Hz/60Hz 00/01 0E
Hum LPF 250–6.3k/Bypass *11 0F
Hum Level 0–127 00–7F 10
M/S Mono/Stereo 00–01 11
# Balance D> 0E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Pan(Mono) L63–0–R63 00–7F 15
Level 0–127 00–7F 16
❍ Effects that connect two types of effect in
series (series 2)
35 : OD → Chorus 02 00
OD Drive 0–48–127 00–7F 03
+ OD Pan L63–0–R63 00–7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
Cho Dly 0–1.0ms–100ms *1 08
Cho Rate 0.05–0.45–10.0 *6 09
Cho Depth 0–72–127 00–7F 0A
# Cho Bal D> 0E–D=E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–80–127 00–7F 16
Parameter Setting Value Value (Hex.) MSB/LSB (H)
36 : OD→ Flanger 02 01
OD Drive 0–48–127 00–7F 03
+ OD Pan L63–0–R63 00–7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
FL Dly 0–1.6ms–100ms *1 08
FL Rate 0.05–0.60–10.0 *6 09
FL Depth 0–40–127 00–7F 0A
FL Fb -98%–+80%–+98% 0F–71 0B
# FL Bal D> 0E–D>49E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–80–127 00–7F 16
37 : OD → Delay 02 02
OD Drive 0–48–127 00–7F 03
+ OD Pan L63–0–R63 00–7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>74E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–80–127 00–7F 16
38 : DS → Chorus 02 03
DS Drive 0–48–127 00–7F 03
+ DS Pan L63–0–R63 00–7F 04
DS Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
DS Amp Sw Off/On 00/01 06
Cho Dly 0–1.0ms–100ms *1 08
Cho Rate 0.05–0.45–10.0 *6 09
Cho Depth 0–72–127 00–7F 0A
# Cho Bal D> 0E–D=E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–72–127 00–7F 16
39 : DS → Flanger 02 04
DS Drive 0–48–127 00–7F 03
+ DS Pan L63–0–R63 00–7F 04
DS Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
DS Amp Sw Off/On 00/01 06
FL Dly 0–1.1ms–100ms *1 08
FL Rate 0.05–0.60–10.0 *6 09
FL Depth 0–24–127 00–7F 0A
FL Fb -98%–+80%–+98% 0F–71 0B
# FL Bal D> 0E–D>49E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–72–127 00–7F 16
40 : DS → Delay 02 05
DS Drive 0–48–127 00–7F 03
+ DS Pan L63–0–R63 00–7F 04
DS Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
DS Amp Sw Off/On 00/01 06
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>74E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–72–127 00–7F 16
